TA2313 is a compact industrial temperature transmitter designed for reliable process-temperature measurement. Its 30 mm installation length provides a short sensing arrangement for compact installations. The 1/2 inch NPT external thread supports industrial process mounting. The Pt 1000 Class A sensing element provides stable temperature measurement with analogue and IO-Link communication. Its compact construction is suitable for machinery, pipelines and general process automation.
Explore performance details, construction highlights, applications, and technical information in one clear overview.
The Pt 1000 element provides reliable resistance-based temperature measurement. The short probe allows the sensing point to be positioned close to the process wall. This can be useful in compact piping and machinery. IO-Link enables digital process-data communication. The analogue output supports conventional temperature-control systems.
The 1/2 inch NPT external thread provides secure mechanical installation. The 30 mm installation length supports compact mounting. The Ø6 mm sensing profile minimises intrusion into the process. The stainless-steel construction supports industrial durability. Proper sealing and tightening should be selected according to the application.
TA2313 can be integrated with standard PLC systems using the analogue output. IO-Link adds remote configuration and diagnostic capabilities. M12 connectivity simplifies field wiring. The transmitter supports industrial temperature monitoring. It is suitable for both standalone and connected automation architectures.
Pt 1000 Class A
30 mm installation length
1/2 inch NPT external thread
Ø6 mm probe
4...20 mA output
IO-Link
M12 connector
Compact design
Stainless-steel construction
Process monitoring
Digital diagnostics
PLC integration
Liquid and gas measurement
Temperature control
Industrial automation
Pipelines
Industrial machinery
Process equipment
Cooling systems
Heating systems
Hydraulic systems
Pumps
Compressors
Machine tools
Liquid monitoring
Gas monitoring
PLC systems
Process automation
Equipment protection
Industrial IoT
| Specification | Details |
|---|---|
| Product Model | TA2313 |
| Type Code | TA-030FLEN12-A-ZVG/US |
| Measuring Element | Pt 1000 |
| Accuracy Class | Class A |
| Measuring Range | Model-specific |
| Factory Setting | Model-specific |
| Installation Length | 30 mm |
| Probe Diameter | 6 mm |
| Process Connection | 1/2 inch NPT |
| Electrical Connection | M12 × 1 |
| Analogue Output | 1 |
| Output | 4...20 mA |
| Communication | IO-Link |
| Media | Liquids and gases |
| Supply | Model-specific |
| Housing | Stainless steel |
| Probe | Cylindrical |
| Mounting | Threaded |
| Protection | Model-specific |
| Diagnostics | IO-Link |
| Installation | Process mounted |
| Application | General industrial |
| PLC Integration | Yes |
| Pack Quantity | 1 pcs |
