Explore performance details, construction highlights, applications, and technical information in one clear overview.
The Plarailchain HPU is a high-performance hydraulic power unit designed for reliable power transmission in industrial automation and mobile systems. It provides precise, controlled motion by converting hydraulic energy into mechanical output, making it ideal for applications requiring consistent force and speed over long travel distances.
The HPU features a robust body constructed from PA6 with 20% glass fiber reinforcement (PA6 GF20%), offering excellent strength-to-weight ratio and resistance to wear under operational stress. This construction ensures durability in demanding environments while maintaining dimensional stability during prolonged use.
The unit is equipped with flaps that can be opened on either side, allowing for flexible installation orientation depending on the application layout or space constraints. This dual-side access simplifies integration into existing mechanical systems without requiring specific mounting direction.
The Plarailchain HPU is rated to operate with a maximum cable or tubing weight of 6 kg/m and supports a maximum traveling speed of 2.5 m/s, ensuring efficient performance across a range of dynamic load conditions. It can function reliably within a service temperature range of -10°C to +80°C, making it suitable for both cold and hot industrial environments.
The Plarailchain HPU is available in standard configurations with no color variants specified. All units are designed for consistent performance and are typically supplied as part of a complete power transmission system, with specific models such as the HPU306-R being available for reference.
Installation is supported through standardized flange and connection points that align with common industrial mounting standards. The dual-side flap design allows for secure attachment on either side of the housing, enabling straightforward integration into existing mechanical or rail-based systems.
| Specification | Details |
|---|---|
| Max. cable
