The IFM MK5900 T-slot cylinder sensor is designed for dependable piston-position detection on pneumatic cylinders with T-slots. The MKI3020-BPKG/A/AS version uses a compact construction with a practical mounting concept for quick cylinder installation. It is suitable for automated pneumatic systems, machine tools, handling equipment and industrial automation applications where accurate cylinder end-position feedback is required.
Explore performance details, construction highlights, applications, and technical information in one clear overview.
The MK5900 is a T-slot cylinder sensor developed for detecting the position of magnetic pistons in compatible pneumatic cylinders. Its compact MKI3020 design allows the sensor to be positioned directly within the cylinder slot. The sensor is designed to provide reliable switching feedback to an automation controller. Its construction supports convenient installation and adjustment during machine setup.
The sensor detects the magnetic field generated by the piston magnet as the piston moves through the sensing area. Its T-slot construction allows the sensor to be positioned along the cylinder body according to the required switching point. The compact housing helps maintain a low-profile installation. This makes it useful for pneumatic automation where accurate piston-position feedback is essential.
The MK5900 is designed for T-slot cylinders and uses a fastening arrangement intended to simplify installation and adjustment. IFM documentation describes the sensor as suitable for T-slot cylinders and provides a compact mounting arrangement with a yellow switching-status LED. The sensor can therefore be positioned efficiently without requiring a large external mounting structure.
The MK5900 is suitable for pneumatic actuators used in automated machinery, material handling and production equipment. It can provide feedback when a piston reaches a defined position, allowing the PLC or controller to continue the machine sequence. Its compact T-slot installation is valuable in space-conscious machine designs. The sensor supports reliable position monitoring in repetitive pneumatic operations.
T-slot cylinder sensor design
MKI3020 sensor construction
Magnetic piston position detection
Compact installation profile
Suitable for T-slot cylinders
Easy position adjustment
Yellow switching-status LED
Reliable switching feedback
Suitable for pneumatic automation
Industrial IFM sensor construction
Pneumatic actuator monitoring
Cylinder end-position detection
Assembly automation
Packaging machinery
Material handling systems
Machine automation
Pneumatic control systems
Pick-and-place equipment
Industrial production lines
Factory automation
| Specification | Details |
|---|---|
| Product Code | MK5900 |
| Model | MKI3020-BPKG/A/AS |
| Brand | IFM |
| Product Type | T-slot cylinder sensor |
| Sensor Principle | Magnetic sensing |
| Cylinder Type | T-slot cylinder |
| Target | Magnetic piston |
| Mounting | T-slot mounting |
| Installation | Slot installation |
| Housing | Compact sensor housing |
| Electrical Design | Sensor switching output |
| Connection | Sensor connection |
| Connector | Model-dependent connection |
| Display | Yellow LED |
| Detection | Piston position |
| Switching Function | Position-dependent switching |
| Mounting Adjustment | Adjustable along cylinder slot |
| Housing Material | PA-based sensor construction |
| Fastening | Integrated fastening element |
| Protection | IP65/IP67 family design |
| Operating Temperature | Model-specific |
| Dimensions | Approx. compact cylinder-sensor format |
| Weight | Approx. 12.4 g |
| Application | Pneumatic position monitoring |
| Category | Sensors / Cylinder Sensors |
