MK5251 is a high-protection T-slot cylinder sensor with a GMR sensing cell. It provides two normally open PNP outputs for position detection. The sensor operates from 10…30 V DC and supports 6000 Hz switching. IP65, IP67 and IP69K protection makes it suitable for demanding washdown environments. Its two short PVC cable sections and M12 connection provide flexible machine integration.
Explore performance details, construction highlights, applications, and technical information in one clear overview.
MK5251 uses a GMR cell for reliable magnetic piston detection. Its magnetic sensitivity is 2.8 mT. The sensor provides two normally open outputs. This allows dual position information from one sensor assembly. The 6000 Hz switching frequency supports fast pneumatic movement.
The sensor provides IP65, IP67 and IP69K protection. This makes it suitable for demanding cleaning and washdown environments. The operating temperature range is -25…85 °C. The housing uses PA with a stainless-steel fastening clamp. These characteristics support food and beverage machinery.
MK5251 measures 25 × 5 × 6.5 mm. The self-clamping fastening system supports quick T-slot mounting. Two 0.3 m PVC cables are provided. The connection uses an A-coded M12 connector. Two rubber positioning stops and cable clips are included.
GMR sensing cell
Two normally open outputs
PNP design
10…30 V DC
<10 mA consumption
100 mA output current
6000 Hz switching
2.8 mT sensitivity
IP65/IP67/IP69K
Food-industry compatible protection
0.3 m PVC cables
M12 connector
Stainless-steel locking nut
PA housing
Yellow LED
Self-clamping fixture
25 × 5 × 6.5 mm
Food processing
Beverage machinery
Washdown equipment
Pneumatic cylinders
Packaging machinery
Robotic systems
Assembly equipment
Material handling
Production lines
Hygienic automation
IP69K protection supports high-pressure cleaning environments. The sensor is suitable for machines exposed to frequent washdown. Its protective construction helps reduce ingress risk. The wide temperature range supports industrial operation. This makes it suitable for demanding production environments.
Two normally open outputs provide additional switching capability. The GMR sensing cell supports reliable piston detection. High switching frequency supports fast pneumatic sequences. The M12 connection provides robust machine wiring. This makes MK5251 useful for advanced cylinder monitoring.
| Specification | MK5251 |
|---|---|
| Manufacturer | ifm electronic |
| Model | MK5251 |
| Product type | T-slot cylinder sensor |
| Order code | MKT3028BBPKG/G/0,3M/-H/US/2X |
| Sensor technology | GMR |
| Electrical design | PNP |
| Output function | 2 × normally open |
| Supply voltage | 10…30 V DC |
| Current consumption | <10 mA |
| Protection class | III |
| Reverse polarity | Yes |
| Power-on delay | 30 ms |
| Output current | 100 mA each |
| Voltage drop | 2.5 V |
| Switching frequency | 6000 Hz |
| Short-circuit protection | Yes |
| Overload protection | Yes |
| Magnetic sensitivity | 2.8 mT |
| Travel speed | <10 m/s |
| Hysteresis | <1.5 mm |
| Repeatability | <0.2 mm |
| Dimensions | 25 × 5 × 6.5 mm |
| Mounting | Flush |
| Cylinder type | T-slot |
| Housing | PA |
| Clamp | Stainless steel |
| Cable 1 | 0.3 m PVC |
| Cable 2 | 0.3 m PVC |
| Connector | M12 A-coded |
| Protection | IP65/IP67/IP69K |
