The IFM MK5123 T-slot cylinder sensor is designed for magnetic piston position detection in pneumatic cylinders where extended cable reach is required. Its MKT2028BARKG construction provides a compact GMR-based sensing solution, while the 6.0 m cable configuration supports connection to remote machine wiring points. The sensor is suitable for packaging, handling, assembly and industrial automation equipment. It provides practical actuator feedback for automated machine sequencing and production processes.
Explore performance details, construction highlights, applications, and technical information in one clear overview.
The MK5123 uses a GMR sensing principle to detect the magnetic piston inside a compatible pneumatic cylinder. The contactless detection method supports repeated cylinder movement. It can provide switching feedback for machine controllers and PLCs. This enables automated sequencing based on actuator position. The sensor is suitable for repetitive industrial operation.
The 6.0 m cable provides extended connection distance for larger machines. This can be useful when pneumatic cylinders are installed far from control cabinets or junction boxes. The integrated cable helps reduce the immediate requirement for additional extension wiring. It supports flexible sensor placement within large equipment. This is especially useful in distributed automation systems.
The MK5123 can be integrated into automated control systems for cylinder position feedback. Its compact sensor body remains suitable for direct T-slot installation. The sensing position can be adjusted according to the cylinder movement requirements. The cable can be routed through machine structures. This supports practical installation in larger production equipment.
GMR cell sensing
T-slot cylinder mounting
6.0 m cable
Magnetic piston detection
Compact sensor housing
Extended wiring reach
Suitable for repetitive movements
Machine controller integration
Industrial automation design
Easy cylinder position monitoring
Large automation machines
Pneumatic cylinder monitoring
Packaging lines
Material handling
Assembly systems
Production equipment
Remote control installations
Machine sequencing
Actuator monitoring
Industrial automation
| Specification | Details |
|---|---|
| Product Code | MK5123 |
| Model | MKT2028BARKG/G/6,0M/ZH |
| Product Type | T-slot cylinder sensor |
| Operating Principle | GMR cell |
| Cylinder Type | T-slot |
| Electrical Design | Model-specific – verify datasheet |
| Output Function | Normally open family variant |
| Operating Voltage | Model-specific |
| Current Consumption | Model-specific |
| Protection Class | III family design |
| Reverse Polarity Protection | Yes, family design |
| Power-on Delay | Model-specific |
| Response Sensitivity | Model-specific |
| Travel Speed | Model-specific |
| Switching Frequency | Model-specific |
| Output Current | Model-specific |
| Short-Circuit Protection | Model-specific |
| Overload Protection | Model-specific |
| Cable Length | 6.0 m |
| Cable Configuration | Integrated cable |
| Mounting | T-slot |
| Housing | PA family design |
| Fastening Clamp | Stainless steel family design |
| Display | Switching-status LED |
| Brand | IFM |
