The IFM KD5019 is a rectangular DC NPN capacitive sensor designed for long-range detection. It provides a 60 mm adjustable sensing range with selectable normally open and normally closed operation. The sensor operates from 10 to 36 V DC and provides a 250 mA continuous output. Its IP65 housing and increased immunity support industrial applications. Terminal wiring provides a robust connection for machine control systems.
Explore performance details, construction highlights, applications, and technical information in one clear overview.
The KD5019 uses an NPN output stage for control systems requiring sinking-type sensor outputs. Its 60 mm sensing range provides useful detection distance for tanks and larger process equipment. The actual sensing range is 60 ±10%. Operating distance is 0 to 48.6 mm. The sensing range can be adjusted during commissioning.
The sensor operates from 10 to 36 V DC and consumes 15 mA at 24 V. It provides selectable normally open and normally closed output operation. The continuous output current is 250 mA with 10 Hz switching frequency. Short-circuit and overload protection are integrated. Reverse polarity protection is also included.
The KD5019 has a 105 × 80 × 40 mm rectangular PPE-modified housing. It is designed for non-flush mounting and provides IP65 protection. Increased immunity improves resistance to conducted interference. A yellow LED indicates switching status. The sensor uses terminal connection with conductors up to 2.5 mm² and an M20 × 1.5 cable gland.
60 mm sensing range
Adjustable sensing range
DC NPN output
NO / NC selectable
10...36 V DC
15 mA at 24 V
250 mA output current
10 Hz switching frequency
Short-circuit protection
Overload protection
Reverse polarity protection
Yellow LED
PPE-modified housing
105 × 80 × 40 mm
Non-flush mounting
IP65 protection
Increased noise immunity
Terminal connection
M20 × 1.5 cable gland
MTTF 550 years
Tank level monitoring
Liquid level detection
Bulk material detection
Container monitoring
Packaging systems
Filling machinery
Process automation
Conveyor systems
Material presence detection
Industrial automation
The NPN output makes the KD5019 suitable for automation systems using sinking inputs. Selectable NO/NC operation provides additional control flexibility. The 60 mm range supports detection of larger targets and material levels. The adjustable sensing range simplifies commissioning. Integrated electrical protection supports reliable machine operation.
The rectangular housing provides a stable mounting format for machine panels and process equipment. Terminal wiring supports industrial conductor sizes. The yellow LED allows quick visual verification of sensor status. IP65 protection supports general industrial environments. The M20 × 1.5 cable entry provides a secure field-wiring arrangement.
| Specification | KD5019 |
|---|---|
| Product type | Capacitive sensor |
| Order code | KDE3060-FNKG/NI |
| Measuring principle | Capacitive |
| Electrical design | NPN |
| Output function | NO / NC selectable |
| Sensing range | 60 mm |
| Adjustable sensing | Yes |
| Real sensing range | 60 ±10% |
| Operating distance | 0...48.6 mm |
| Hysteresis | 1...15% |
| Switch-point drift | -15...15% |
| Glass correction | 0.4 |
| Water correction | 1 |
| Ceramics correction | 0.2 |
| PVC correction | 0.2 |
| Operating voltage | 10...36 V DC |
| Current consumption | 15 mA at 24 V |
| Protection class | II |
| Reverse polarity protection | Yes |
| Voltage drop | 2.5 V max. |
| Continuous output current | 250 mA |
| Switching frequency | 10 Hz |
| Short-circuit protection | Yes |
| Overload protection | Yes |
| Ambient temperature | -25...80°C |
| Protection rating | IP65 |
| Increased immunity | Yes |
| Housing | PPE modified |
| Dimensions | 105 × 80 × 40 mm |
| Mounting | Non-flush |
| Weight | 296.5 g |
| Indicator | Yellow LED |
| Connection | Terminals |
| Cable gland | M20 × 1.5 |
| Terminal capacity | Up to 2.5 mm² |
| MTTF | 550 years |
