The IFM KD0009 is a rectangular capacitive sensor designed for long-range non-contact detection. It provides an adjustable sensing range of 60 mm. The sensor uses a combined AC/DC output with selectable normally open and normally closed operation. Its robust PPE-modified housing and increased noise immunity support harsh industrial environments. The sensor uses terminal connection with an M20 × 1.5 cable gland.
Explore performance details, construction highlights, applications, and technical information in one clear overview.
The KD0009 provides a 60 mm sensing range for applications requiring greater detection distance. The sensing range can be adjusted through the integrated potentiometer. Its real sensing range is 60 ±10%, with an operating distance of 0 to 48.6 mm. Hysteresis is 1 to 15% of Sr. This makes the sensor suitable for large containers, tanks and bulk-material applications.
The sensor operates from 20 to 250 V AC/DC. It provides selectable normally open/normally closed output functionality. Continuous output current is 200 mA, with a short-time current rating of 1500 mA for 20 ms at 0.5 Hz. Switching frequency is 10 Hz for both AC and DC. Short-circuit and overload protection are not integrated.
The KD0009 uses a rectangular PPE-modified housing measuring 105 × 80 × 40 mm. It is designed for non-flush mounting and provides IP65 protection. Increased immunity improves resistance to conducted RF interference. A yellow LED provides switching-status indication. Terminal wiring supports conductors up to 2.5 mm² with an M20 × 1.5 cable gland.
60 mm sensing range
Adjustable sensing range
Selectable NO / NC output
AC/DC operation
20...250 V AC/DC
Two-wire technology
10 Hz AC switching
10 Hz DC switching
200 mA continuous current
1500 mA short-time current
Yellow LED
PPE-modified housing
105 × 80 × 40 mm
Non-flush mounting
IP65 protection
Increased noise immunity
Potentiometer adjustment
M20 × 1.5 cable gland
Terminal connection
Tank level detection
Bulk material monitoring
Liquid level monitoring
Container detection
Conveyor applications
Filling machinery
Packaging equipment
Process automation
Material presence detection
Industrial level control
The 60 mm sensing range allows the KD0009 to monitor targets from greater distances than compact capacitive sensors. This is useful for large containers and material-level applications. Adjustable sensing allows the switching point to be optimized during commissioning. The robust rectangular housing provides a stable mounting format. The sensor can therefore support larger-scale industrial detection tasks.
The combined AC/DC output allows the sensor to operate in different supply architectures. Selectable NO/NC functionality provides additional control flexibility. Terminal wiring accommodates industrial conductor sizes up to 2.5 mm². A fast-acting miniature fuse of up to 2 A is specified for protection. Because short-circuit and overload protection are not integrated, installation protection is important.
| Specification | KD0009 |
|---|---|
| Product type | Capacitive sensor |
| Order code | KDE2060-FBOA/NI |
| Measuring principle | Capacitive |
| Electrical design | AC/DC |
| Output function | NO / NC selectable |
| Sensing range | 60 mm |
| Sensing range adjustable | Yes |
| Factory setting | 60 mm |
| Real sensing range | 60 ±10% |
| Operating distance | 0...48.6 mm |
| Hysteresis | 1...15% |
| Switch-point drift | -15...15% |
| Glass correction | 0.4 |
| Water correction | 1 |
| Ceramics correction | 0.2 |
| PVC correction | 0.2 |
| Operating voltage | 20...250 V AC/DC |
| Protection class | II |
| Reverse polarity protection | No |
| Max. voltage drop DC | 8 V |
| Max. voltage drop AC | 10 V |
| Minimum load current | 5 mA |
| Leakage current | 2.5 / 1.7 / 1.3 mA |
| Continuous current AC | 200 mA |
| Continuous current DC | 200 mA |
| Short-time current | 1500 mA |
| Switching frequency AC | 10 Hz |
| Switching frequency DC | 10 Hz |
| Short-circuit protection | No |
| Overload protection | No |
| Ambient temperature | -25...80°C |
| Protection rating | IP65 |
| Housing | PPE modified |
| Dimensions | 105 × 80 × 40 mm |
| Mounting | Non-flush |
| Weight | 299.5 g |
| Indicator | Yellow LED |
| Connection | Terminals, M20 × 1.5 gland |
