The IFM KB0025 is a cylindrical capacitive sensor designed for reliable non-contact detection of materials. It provides an adjustable sensing range of 3 to 20 mm for flexible machine setup. The sensor uses a normally open AC/DC output and operates from 20 to 250 V AC/DC. Its smooth PBT housing and increased noise immunity support dependable industrial operation. A 2 m PVC cable provides direct connection to the control system.
Explore performance details, construction highlights, applications, and technical information in one clear overview.
The KB0025 uses capacitive sensing to detect both metallic and non-metallic materials without mechanical contact. Its sensing range can be adjusted from 3 to 20 mm using the integrated adjustment mechanism. The real sensing range is 20 ±10%, with an operating distance of 0 to 16.2 mm. Correction factors are specified for glass, water, ceramics and PVC. This makes the sensor suitable for material presence and level monitoring.
The sensor operates across a wide 20 to 250 V AC/DC supply range. It provides a normally open switching output with a continuous current rating of 200 mA. The maximum voltage drop is 8 V on DC and 10 V on AC. Switching frequency is 25 Hz on AC and 40 Hz on DC. The sensor does not provide short-circuit or overload protection, so the specified external protection should be used.
The KB0025 has a cylindrical PBT housing measuring 34 mm in diameter and 81 mm in length. It is designed for non-flush mounting and includes a yellow switching-status LED. The sensor has IP65 protection and increased immunity to conducted radio-frequency interference. Its ambient operating range is -25 to 70°C. The supplied 2 m PVC cable uses two 0.5 mm² conductors.
Adjustable 3...20 mm sensing range
Normally open output
20...250 V AC/DC operation
Two-wire technology
25 Hz AC switching frequency
40 Hz DC switching frequency
200 mA continuous output current
Adjustable sensing range
Yellow switching LED
PBT cylindrical housing
34 mm diameter
81 mm total length
Non-flush mounting
IP65 protection
Increased noise immunity
2 m PVC cable
2 × 0.5 mm² conductors
Glass/water/ceramics/PVC correction factors
Liquid level monitoring
Dry bulk material detection
Container level detection
Material presence sensing
Packaging machinery
Filling equipment
Conveyor systems
Process automation
Tank monitoring
Industrial automation
The cylindrical body provides a familiar mounting format for industrial machine construction. The adjustable sensing range allows the sensor to be tuned to the actual target position. The 2 m cable simplifies direct connection to control equipment. The yellow LED provides immediate visual switching feedback. The smooth housing also helps reduce material accumulation around the sensor.
The PBT housing provides a robust construction for industrial environments. IP65 protection helps protect the sensor against dust and water jets. Increased immunity improves operation where conducted RF interference may be present. The wide supply range allows use in AC and DC control systems. Correct external fuse protection should be provided because the output is not internally short-circuit protected.
| Specification | KB0025 |
|---|---|
| Product type | Capacitive sensor |
| Order code | KB-2020-ABOA/NI |
| Measuring principle | Capacitive |
| Electrical design | AC/DC |
| Output function | Normally open |
| Technology | Two-wire |
| Sensing range | 3...20 mm |
| Factory setting | 20 mm |
| Real sensing range Sr | 20 ±10% |
| Operating distance | 0...16.2 mm |
| Hysteresis | 1...15% of Sr |
| Switch-point drift | -15...15% |
| Correction factor – glass | 0.4 |
| Correction factor – water | 1 |
| Correction factor – ceramics | 0.2 |
| Correction factor – PVC | 0.2 |
| Operating voltage | 20...250 V AC/DC |
| Protection class | II |
| Reverse polarity protection | No |
| Max. voltage drop DC | 8 V |
| Max. voltage drop AC | 10 V |
| Minimum load current | 5 mA |
| Continuous current | 200 mA |
| Short-time current | 1500 mA / 20 ms / 0.5 Hz |
| Switching frequency AC | 25 Hz |
| Switching frequency DC | 40 Hz |
| Short-circuit protection | No |
| Overload protection | No |
| Ambient temperature | -25...70°C |
| Protection rating | IP65 |
| Housing | PBT cylindrical |
| Dimensions | Ø34 × 81 mm |
| Mounting | Non-flush |
| Weight | 284.5 g |
| Cable | 2 m PVC, 2 × 0.5 mm² |
| Indicator | Yellow LED |
