The IFM DP4302 counter is an IO-Link signal conditioner designed for decentralized pulse counting in industrial automation systems. It can evaluate pulse signals up to 2,000 Hz for object, batch and consumption counting applications. Its IP69K protection and local display make it suitable for demanding industrial environments and machine-level monitoring.
Explore performance details, construction highlights, applications, and technical information in one clear overview.
DP4302 is designed to evaluate pulse signals and provide decentralized counting functions. It can be integrated into IO-Link systems and used to monitor production quantities, machine cycles or consumption-related pulses. The device helps move counting functions closer to the machine and simplifies centralized control requirements.
The DP4302 supports two digital inputs for counter and function signals and provides IO-Link communication with switching outputs. It can evaluate pulses up to 2,000 Hz. This makes it suitable for high-speed counting applications in automated production and monitoring systems.
DP4302 combines pulse counting, local monitoring and IO-Link connectivity in a compact device. It can simplify machine architectures by performing counting directly at the application. The IP69K protection further supports use in demanding industrial environments.
Pulse counter
Counting up to 2,000 Hz
IO-Link communication
2 digital inputs
Switching outputs
Local display
Decentralized counting
IP69K protection
Object and batch counting
Industrial automation integration
Object counting
Batch counting
Production monitoring
Consumption measurement
Conveyor systems
Packaging machines
| Specification | Details |
|---|---|
| Product Code | DP4302 |
| Product Type | Counter |
| Communication | IO-Link |
| Inputs | 2 × digital inputs |
| Maximum Pulse Frequency | Up to 2,000 Hz |
| Outputs | IO-Link and switching outputs |
| Protection | IP69K |
| Function | Pulse counting |
| Application | Object / batch / consumption counting |
| Brand | IFM |
