IFM E30429 is a DIN rail mounting kit designed specifically for compatible IO-Link display units. It provides a convenient way to mount the display securely onto a standard control cabinet or electrical enclosure DIN rail. The mounting clip uses PA and stainless steel 1.4567/V2A materials for a practical combination of strength and durability. It is designed for ambient temperatures from -25 to 80°C. The kit weighs approximately 17 g and includes two Torx T10 K30 × 15 fixing screws. E30429 provides a compact mounting solution for integrating compatible IO-Link displays into industrial control panels.
Explore performance details, construction highlights, applications, and technical information in one clear overview.
DIN rail mounting provides a standard and organised method for installing electrical and automation components inside control cabinets. E30429 allows compatible IO-Link display units to be fixed directly to the DIN rail. This avoids the need for custom mounting brackets or drilling additional holes in the control panel. The clip helps maintain a clean arrangement of display and automation components. It is particularly useful where control cabinet space needs to be organised efficiently.
The E30429 is specifically designed as a mounting accessory for IO-Link display units. It can be used with compatible IFM displays such as the E30430 family arrangement. The clip provides mechanical support while keeping the display accessible for operator observation. This makes it useful in applications where IO-Link process values need to be visible inside or near a control cabinet.
The DIN rail clip uses PA and stainless steel 1.4567/V2A materials. This provides a practical combination of low weight and mechanical strength. The unit weighs approximately 17 g and is rated for ambient temperatures between -25 and 80°C. Two Torx T10 K30 × 15 screws are included with the mounting kit. The compact construction allows quick installation without adding significant weight or space requirements.
DIN rail mounting kit
Designed for IO-Link display units
Standard control cabinet installation
PA and stainless-steel construction
-25 to 80°C ambient temperature range
Approx. 17 g weight
Includes two Torx T10 K30 × 15 screws
Compact mounting solution
Supports organised panel installation
Easy installation on DIN rail
IO-Link display mounting
Control cabinet installation
Industrial automation panels
Machine control systems
Factory automation
Process monitoring panels
Electrical enclosures
Industrial instrumentation
| Specification | Details |
|---|---|
| Product Code | E30429 |
| Product Type | DIN Rail Clip |
| Product Designation | DIN Rail Mounting Kit |
| Application | IO-Link display unit |
| Mounting Method | DIN rail |
| Ambient Temperature | -25 to 80°C |
| Material | PA; stainless steel 1.4567 / V2A |
| Weight | Approx. 17 g |
| Included Hardware | 2 × Torx T10 K30 × 15 |
| Pack Quantity | 1 pc. |
| Main Function | DIN rail mounting |
