The IFM DP4122 speed monitor is an IO-Link signal conditioner designed to measure and display rotational speed-related pulse signals from 0.1 to 2,000 Hz. It provides IO-Link communication and switching outputs for decentralized monitoring. Its IP69K-rated housing makes it suitable for demanding industrial and hygienic environments.
Explore performance details, construction highlights, applications, and technical information in one clear overview.
The DP4122 is an IO-Link speed monitoring device designed to evaluate pulse signals and provide a clear indication of current speed. It is suitable for decentralized machine monitoring where speed information needs to be processed close to the machine. The device supports integration into modern IO-Link automation architectures.
DP4122 accepts pulse-related digital inputs and provides IO-Link communication together with switching outputs. It can process speed signals from 0.1 to 2,000 Hz and provides speed display functionality with colour change. Its IP69K protection supports demanding industrial environments.
DP4122 combines speed monitoring, local display and IO-Link communication in one compact device. It reduces the need for separate signal-processing equipment and enables decentralized monitoring. Its high protection rating makes it suitable for applications where frequent cleaning or demanding environmental conditions are present.
Speed monitoring
Measuring range 0.1 to 2,000 Hz
IO-Link communication
Digital pulse input
Local speed display
Colour-change display
Switching output
IP69K protection
Decentralized signal processing
Industrial automation integration
Motor speed monitoring
Conveyor systems
Rotating machinery
Production equipment
Machine condition monitoring
Industrial automation
| Specification | Details |
|---|---|
| Product Code | DP4122 |
| Product Type | Speed monitor |
| Communication | IO-Link |
| Measuring Range | 0.1 to 2,000 Hz |
| Input | 2 × digital inputs |
| Output | IO-Link and switching outputs |
| Display | Speed display with colour change |
| Protection | IP69K |
| Application | Speed monitoring |
| Brand | IFM |
