Product Overview

The MZC1 VIA is a compact, robust cylinder sensor designed for precise position detection in industrial automation environments. Featuring a C-slot cylinder type with compatibility across various cylinder types—including SMC rail CDQ2 and ECDQ2, round body cylinders, profile cylinders, and tie-rod cylinders—this sensor offers flexible integration into diverse mechanical systems. Equipped with a yellow LED indicator for visual installation guidance, the MZC1 VIA provides reliable switching output via PNP configuration. Its IP68 enclosure rating ensures complete protection against dust and submersion, making it ideal for harsh or wet environments. With support for IO-Link functionality, users can adjust switch-on or switch-off delays up to 1.6 seconds, enabling fine-tuned response timing in dynamic applications.

Key Features and Technology

The MZC1 VIA leverages advanced sensing technology with a built-in encoder magnet that measures the distance traveled during signal output—dependent on supply voltage (U_B) and ambient temperature (T_a). This enables accurate position feedback for precise process control. The sensor supports both NC and NO switching functions via IO-Link, allowing flexible logic integration. A visual LED indicator simplifies installation by providing real-time status visibility. Interior housing temperature can be monitored through IO-Link, enabling predictive maintenance and thermal condition tracking. The sensor includes reverse polarity protection, short-circuit protection, and power-up pulse protection—ensuring safe operation even under fault conditions. Its high switching frequency of 1,000 Hz ensures fast response times for dynamic motion detection.

Technical Characteristics

The MZC1 VIA operates with a supply voltage range of 10 V DC to 30 V DC and maintains a maximum voltage drop of ≤ 2.5 V. It draws a continuous current (I_a) of ≤ 100 mA, ensuring energy efficiency. The housing length is 23.7 mm, contributing to its compact design. Electrical wiring uses a DC 3-wire configuration with a cable featuring M8, 3-pin plug and knurled nut for secure connection—suitable for drag chain applications. Cable diameter is Ø 2.2 mm. Protection class is III, meeting safety standards for high-risk environments. The sensor supports IO-Link for configurable switch-on or switch-off delays up to 1.6 seconds (NC or NO), enabling adaptive response timing in process automation.

Configuration and Integration

The MZC1 VIA integrates seamlessly into existing systems via its DC 3-wire electrical connection and IO-Link interface. Users can configure switch-on or switch-off delays up to 1.6 seconds through the IO-Link protocol, allowing customization of response timing based on application needs. The sensor supports both NO and NC output functions, providing flexibility in circuit design. Its compatibility with a wide range of cylinder types—including SMC rail CDQ2, ECDQ2, round body, profile, and tie-rod cylinders—ensures broad applicability across automation setups. The visual LED indicator aids installation by clearly showing operational status. IO-Link also enables remote monitoring of interior housing temperature, supporting real-time diagnostics and system health assessment.

Operating Environment

The MZC1 VIA is engineered for operation in extreme ambient conditions, with a specified range from –30 °C to +80 °C. This wide temperature tolerance ensures reliable performance across cold storage, high-heat processing, and outdoor industrial environments. The IP68 enclosure rating provides full dust protection and submersion resistance, making it suitable for use in wet or dirty conditions such as water exposure or splash zones. The sensor is designed to operate safely under reverse polarity, short-circuit, and power-up pulse conditions due to built-in protective features. These characteristics ensure consistent performance even in challenging industrial settings where environmental variability is common.

Industrial Applications

The MZC1 VIA is ideal for use in automated machinery where precise position detection is required—such as robotic arms, packaging lines, and material handling systems. Its compatibility with profile cylinders and tie-rod cylinders makes it suitable for integration into complex mechanical assemblies. The sensor’s high switching frequency (1,000 Hz) supports fast motion monitoring, while IO-Link enables advanced diagnostics and adaptive control. Applications include detection of cylinder travel distance, end-of-stroke confirmation, and real-time feedback in safety-critical systems. Its robust design and environmental resilience ensure long-term reliability in demanding industrial processes where continuous operation is essential.
