Explore performance details, construction highlights, applications, and technical information in one clear overview.
The nominal sensing distance is 4…25 mm.
The nominal sensing distance is 4…25 mm. A switching frequency of 50 Hz.
The thermal drift Sr is < 20%, with repeat accuracy of 5%.
The output type is PNP. The output function is NO + NC.
The operating voltage is 10-40 VDC, with load current of ≤200 mA. No-load supply current is ≤10 mA and leakage current is limited to ≤ 10 µA.
Maximum ripple is ≤10%. Short-circuit protection is Yes, Automatic reset. Reverse polarity protection is Yes. Surge protection is Yes.
Ingress protection is rated IP 67 NEMA 1,3,4,6,13.
The housing is PC, while the active head uses PC. Dimensions are 55x35x15 mm and the connection is 2 m PVC Cable.
Weight is 150 g.
The operating temperature range is -25 °C…+80 °C (Non-freezing).
Storage temperature is -40 °C…+85 °C.
Sensitivity adjustment is Yes.
The manufacturer part number is CQ55/BP-3A. This model is manufactured by M.D. Micro Detectors. Installation is Unshielded.
Unshielded is Operating temperature:. Time to availability is ≤100 ms.
For electrical integration, it provides output type PNP, operating voltage 10-40 VDC, switching frequency 50 Hz. The physical configuration includes PC housing, dimensions 55x35x15 mm, 2 m PVC Cable connection. It is rated IP 67 NEMA 1,3,4,6,13 for an operating temperature range of -25 °C…+80 °C (Non-freezing).
| Specification | Details |
|---|---|
| Model | CQ55/BP-3A |
| Manufacturer part number | CQ55/BP-3A |
| Manufacturer | M.D. Micro Detectors |
| Output type | PNP |
| Output function | NO + NC |
| Switching frequency | 50 Hz |
| Weight | 150 g |
| Active head material | PC |
| Housing material | PC |
| Installation | Unshielded |
| Operating temperature | -25 °C…+80 °C (Non-freezing) |
| Dimensions | 55x35x15 mm |
| Connection | 2 m PVC Cable |
| Storage temperature | -40 °C…+85 °C |
| Hysteresis | ≤ 20% |
| Nominal sensing distance | 4…25 mm |
| Sensitivity adjustment | Yes |
| Thermal drift Sr | < 20% |
| Repeat accuracy | 5% |
| Degree of protection | IP 67 NEMA 1,3,4,6,13 |
| Time to availability | ≤100 ms |
| Short-circuit protection | Yes, Automatic reset |
| Reverse polarity protection | Yes |
| Surge protection | Yes |
| Maximum ripple | ≤10% |
| Operating voltage | 10-40 VDC |
| Load current | ≤200 mA |
| No-load supply current | ≤10 mA |
| Leakage current | ≤ 10 µA |
