The nominal sensing distance is 2…20 mm.
The nominal sensing distance is 2…20 mm. A switching frequency of 100 Hz.
The thermal drift Sr is < 20%, with repeat accuracy of 10%.
The output type is NPN. The output function is NC.
The operating voltage is 10 - 30 VDC, with load current of ≤ 200 mA. No-load supply current is 8 mA and leakage current is limited to ≤ 10 mA.
Maximum ripple is ≤10%. Short-circuit protection is Yes, Automatic reset. Reverse polarity protection is Yes. Surge protection is Yes.
Ingress protection is rated IP 65.
The housing is Nickel-plated brass, while the active head uses PBT. Dimensions are M30 / L = 98 mm and the connection is M12 Connector.
Weight is 185 g.
Tightening torque is 50 nm.
The operating temperature range is -25 °C…+70 °C.
Sensitivity adjustment is Yes.
The manufacturer part number is CT1/CN-2H. This model is manufactured by M.D. Micro Detectors. Installation is Unshielded.
Unshielded is Operating temperature:. Time to availability is 100 ms.
For electrical integration, it provides output type NPN, operating voltage 10 - 30 VDC, switching frequency 100 Hz. The physical configuration includes Nickel-plated brass housing, dimensions M30 / L = 98 mm, M12 Connector connection. It is rated IP 65 for an operating temperature range of -25 °C…+70 °C.
| Specification | Details |
|---|---|
| Model | CT1/CN-2H |
| Manufacturer part number | CT1/CN-2H |
| Manufacturer | M.D. Micro Detectors |
| Output type | NPN |
| Output function | NC |
| Switching frequency | 100 Hz |
| Weight | 185 g |
| Active head material | PBT |
| Housing material | Nickel-plated brass |
| Tightening torque | 50 nm |
| Installation | Unshielded |
| Operating temperature | -25 °C…+70 °C |
| Dimensions | M30 / L = 98 mm |
| Connection | M12 Connector |
| Hysteresis | ≤ 20% |
| Nominal sensing distance | 2…20 mm |
| Sensitivity adjustment | Yes |
| Thermal drift Sr | < 20% |
| Repeat accuracy | 10% |
| Degree of protection | IP 65 |
| Time to availability | 100 ms |
| Short-circuit protection | Yes, Automatic reset |
| Reverse polarity protection | Yes |
| Surge protection | Yes |
| Maximum ripple | ≤10% |
| Operating voltage | 10 - 30 VDC |
| Load current | ≤ 200 mA |
| No-load supply current | 8 mA |
| Leakage current | ≤ 10 mA |
