The IFM KQ6007 is a compact rectangular capacitive sensor with a 12 mm sensing range and IO-Link communication. It is designed for detecting liquids and dry bulk material through non-metallic container walls or on bypass pipes. The sensor provides a selectable PNP normally-open or normally-closed switching output. It operates from 10–30 V DC and supports up to 100 mA continuous output current. Programming buttons and LED indication simplify local setup and commissioning.
Explore performance details, construction highlights, applications, and technical information in one clear overview.
The KQ6007 is designed specifically for level and material detection around non-metallic containers. Its capacitive principle enables detection through suitable container walls without direct process contact. It can also be installed on bypass pipes. The sensor is suitable for both liquids and dry bulk materials. This provides flexible options for tank, hopper and container monitoring.
The sensor uses a PNP electrical design with selectable normally-open or normally-closed operation. Its maximum switching-output voltage drop is 2.5 V. Continuous switching current is rated at 100 mA. The switching frequency is 10 Hz. Integrated short-circuit protection improves electrical reliability.
IO-Link communication enables digital parameterisation and integration with modern automation systems. Local programming buttons are also provided on the housing. An LED supplies visual operating and switching feedback. This combination allows setup either directly at the machine or through an IO-Link master. The sensor therefore supports both conventional and connected automation architectures.
12 mm sensing range
Rectangular housing
20 × 14 × 48 mm dimensions
PNP output
NO/NC selectable
IO-Link communication
10–30 V DC supply
100 mA output current
10 Hz switching frequency
2.5 V voltage drop
Programming buttons
LED indication
Short-circuit protection
Through-wall detection
Bypass-pipe installation
Liquid level monitoring
Dry bulk level detection
Plastic container monitoring
Bypass pipe sensing
Tank level control
Powder detection
Granulate detection
Packaging equipment
The 20 × 14 × 48 mm rectangular body is suitable for installations where cylindrical sensors are inconvenient. It can be mounted directly against suitable non-metallic container walls. This enables process detection without drilling a sensor opening into the vessel in appropriate applications. Local programming buttons simplify adjustment after mounting. The compact design is particularly useful in machine and packaging applications.
The KQ6007 operates from a standard 10–30 V DC industrial supply. Protection class III construction is specified. Reverse-polarity protection helps protect the electronics against wiring errors. Short-circuit protection safeguards the switching output. These features support dependable operation in automated equipment.
| Specification | KQ6007 |
|---|---|
| Product type | Capacitive sensor |
| Product code | KQ-3120NFPKG/2T/10M |
| Measuring principle | Capacitive |
| Sensing range | 12 mm |
| Housing | Rectangular |
| Dimensions | 20 × 14 × 48 mm |
| Application | Level/material detection |
| Installation | Non-metallic wall / bypass pipe |
| Media | Liquids / dry bulk |
| Electrical design | PNP |
| Output function | NO/NC selectable |
| Operating voltage | 10–30 V DC |
| Current consumption | <17 mA |
| Protection class | III |
| Reverse polarity | Yes |
| Voltage drop | 2.5 V |
| Continuous current | 100 mA |
| Switching frequency | 10 Hz |
| Short-circuit protection | Yes |
| Communication | IO-Link |
| Adjustment | Programming buttons |
| Indication | LED |
| Detection | Non-contact |
| Through-wall detection | Yes |
| Bypass installation | Yes |
| Output type | Digital switching |
| Sensor format | Flat rectangular |
| Industrial supply | DC |
| Manufacturer | IFM electronic |
| Model | KQ6007 |
