The S8-PR-5-G00-XG - 950801540 - S8 Compact Photoelectric Sensors is a industrial product from Datasensing. The documented values above identify the exact configuration and are the basis for technical selection and system integration.
The Datasensing S8-PR-5-G00-XG - 950801540 is a precision photoelectric sensor designed for industrial automation applications. It features a nominal sensing distance of 30m and operates within a temperature range of -25°C to +55°C (without freeze).
With a storage temperature range of -25°C to +70°C, this sensor ensures reliability across diverse industrial conditions. Its compact form factor and robust specifications make it ideal for applications requiring precise detection in challenging environments.
The documented configuration includes Nominal sensing distance: 30m; Through beam emitter: Radial 90°; Response time: n/a; Emission: LED Red.
The documented configuration includes Output voltage drop: ≤2V@Iload=100mA; Operating Voltage: 12…30VDC; No-Load supply current: ≤ 15mA; Impulsive Overvoltage Protection: Yes; Impulsive Overvoltage Protection: Insulation resistance; Output type: n/a; Output type: Response time.
The documented configuration includes Dimensions: 14x43x25; Storage temperature: - 25°C…+70°C; Operating Temperature: - 25°C…+ 55°C (Without freeze); Mechanical Protection: IP67; Storage temperature: 25°C…+70°C; Operating Temperature: 25°C…+ 55°C (Without freeze); Insulation resistance: >20 MΩ 500 Vdc, between electronics and housing; Short-circuit protection: YES.
The documented configuration includes Reverse Polarity Protection: Yes; Material: Plastic - ABS / PMMA; Housing material: ABS(Housing), PMMA (Optics); Active Head Material: PMMA; Diameter/Dimension: Cubic; Short-circuit protection: Reverse Polarity Protection; Active Head Material: Storage temperature; >20 MΩ 500 Vdc, between electronics and housing: Contact resistance.
The documented configuration includes Function Principle: Through beam emitter; Functions: Through beam emitter; Application: Function Principle.
The documented configuration includes Connections: M8 plug 4pin; Optic position: Radial 90°; Interference to external light: according to EN 60947-5-2 : 2020; Contact resistance: 500 Vac 1 min., between electronics and housing; Shocks and vibrations: 0.5 mm amplitude, 10 … 55 Hz frequency, for every axis (EN60068-2-6); ≤2V@Iload: 100mA.
| Feature | Specification |
|---|---|
| Output voltage drop | ≤2V@Iload=100mA |
| Operating Voltage | 12…30VDC |
| Dimensions | 14x43x25 |
| Connections | M8 plug 4pin |
| Storage temperature | - 25°C…+70°C |
| Operating Temperature | - 25°C…+ 55°C (Without freeze) |
| Mechanical Protection | IP67 |
| Storage temperature | 25°C…+70°C |
| Operating Temperature | 25°C…+ 55°C (Without freeze) |
| Nominal sensing distance | 30m |
| Optic position | Radial 90° |
| No-Load supply current | ≤ 15mA |
| Interference to external light | according to EN 60947-5-2 : 2020 |
| Insulation resistance | >20 MΩ 500 Vdc, between electronics and housing |
| Contact resistance | 500 Vac 1 min., between electronics and housing |
| Shocks and vibrations | 0.5 mm amplitude, 10 … 55 Hz frequency, for every axis (EN60068-2-6) |
| Through beam emitter | Radial 90° |
| ≤2V@Iload | 100mA |
| Impulsive Overvoltage Protection | Yes |
| Impulsive Overvoltage Protection | Insulation resistance |
| Output type | n/a |
| Response time | n/a |
| Short-circuit protection | YES |
| Reverse Polarity Protection | Yes |
| Material | Plastic - ABS / PMMA |
| Housing material | ABS(Housing), PMMA (Optics) |
| Active Head Material | PMMA |
| Diameter/Dimension | Cubic |
| Output type | Response time |
| Short-circuit protection | Reverse Polarity Protection |
| Active Head Material | Storage temperature |
| Function Principle | Through beam emitter |
| Functions | Through beam emitter |
| Emission | LED Red |
| Application | Function Principle |
| >20 MΩ 500 Vdc, between electronics and housing | Contact resistance |
