The S62-PL-5-B01-PP - 956211110 - S62 Compact Photoelectric Sensors is a industrial product from Datasensing. The documented values above identify the exact configuration and are the basis for technical selection and system integration.
The Datasensing S62-PL-5-B01-PP - 956211110 S62 Compact Photoelectric Sensor delivers precise industrial detection with a PNP NO+NC output configuration. This sensor operates within a 10-30VDC range, ensuring compatibility with standard industrial power supplies.
The documented configuration includes Response time: 0,2; Nominal sensing distance: 20m; Emission: according to EN 60947-5-2 : 2020; Emission: LASER Red.
The documented configuration includes Output voltage drop: ≤2V@Iload=100mA; Output type: PNP NO+NC; Output Function: NO+NC; Operating Voltage: 10…30VDC; No-Load supply current: ≤ 30mA; Load current: ≤100mA; Impulsive Overvoltage Protection: Yes; Impulsive Overvoltage Protection: Insulation resistance.
The documented configuration includes Output type: Output Function.
The documented configuration includes Dimensions: 18x50x50; Storage temperature: - 25°C…+70°C; Mechanical Protection: IP67; Storage temperature: 25°C…+70°C; Insulation resistance: >20 MΩ 500 Vdc, between electronics and housing; Short-circuit protection: YES; Reverse Polarity Protection: Yes; Housing material: ABS / PMMA.
The documented configuration includes Active Head Material: PMMA; Diameter/Dimension: Cubic; Short-circuit protection: Reverse Polarity Protection; Material: Housing material; Active Head Material: Storage temperature; >20 MΩ 500 Vdc, between electronics and housing: Contact resistance.
The documented configuration includes Function Principle: Polarized retroreflective; Functions: Polarized retroreflective; Application: Function Principle.
The documented configuration includes Connections: M12 plug; Interference to external light: according to EN 60947-5-2 : 2020; Contact resistance: 500 Vac 1 min., between electronics and housing; Shocks and vibrations: 0.5 mm amplitude, 10 … 55 Hz frequency, for every axis (EN60068-2-6); ≤2V@Iload: 100mA.
| Feature | Specification |
|---|---|
| Output voltage drop | ≤2V@Iload=100mA |
| Output type | PNP NO+NC |
| Output Function | NO+NC |
| Response time | 0,2 |
| Operating Voltage | 10…30VDC |
| Dimensions | 18x50x50 |
| Connections | M12 plug |
| Storage temperature | - 25°C…+70°C |
| Mechanical Protection | IP67 |
| Storage temperature | 25°C…+70°C |
| Nominal sensing distance | 20m |
| No-Load supply current | ≤ 30mA |
| Load current | ≤100mA |
| Interference to external light | according to EN 60947-5-2 : 2020 |
| Insulation resistance | >20 MΩ 500 Vdc, between electronics and housing |
| Contact resistance | 500 Vac 1 min., between electronics and housing |
| Shocks and vibrations | 0.5 mm amplitude, 10 … 55 Hz frequency, for every axis (EN60068-2-6) |
| Emission | according to EN 60947-5-2 : 2020 |
| ≤2V@Iload | 100mA |
| Impulsive Overvoltage Protection | Yes |
| Impulsive Overvoltage Protection | Insulation resistance |
| Short-circuit protection | YES |
| Reverse Polarity Protection | Yes |
| Housing material | ABS / PMMA |
| Active Head Material | PMMA |
| Diameter/Dimension | Cubic |
| Output type | Output Function |
| Short-circuit protection | Reverse Polarity Protection |
| Material | Housing material |
| Active Head Material | Storage temperature |
| Function Principle | Polarized retroreflective |
| Functions | Polarized retroreflective |
| Emission | LASER Red |
| Application | Function Principle |
| >20 MΩ 500 Vdc, between electronics and housing | Contact resistance |
