The S62-PA-5-B01-PN - 956211320 - S62 Compact Photoelectric Sensors is a industrial product from Datasensing. The documented values above identify the exact configuration and are the basis for technical selection and system integration.
The Datasensing S62-:PA-5-B01-PN - 956211320 S62 Compact Photoelectric Sensors deliver reliable detection in demanding industrial environments. These sensors operate within a 10–30VDC range, with a response time of 0.5ms and a nominal sensing distance of 8m.
Engineered for precision and durability, these sensors provide robust performance in harsh industrial settings. The IP67 rating ensures protection against dust and water immersion, while the compact size and M12 connector facilitate easy integration into existing systems.
The documented configuration includes Response time: 0,5; Nominal sensing distance: 8m; Emission: LED Red.
The documented configuration includes Output voltage drop: ≤2V@Iload=100mA; Output type: NPN / PNP; Operating Voltage: 10…30VDC; No-Load supply current: ≤ 30mA; Load current: ≤100mA; Impulsive Overvoltage Protection: Yes; Impulsive Overvoltage Protection: Insulation resistance; Output type: Response time.
The documented configuration includes Dimensions: 18x50x50; Storage temperature: - 25°C…+70°C; Mechanical Protection: IP67; Storage temperature: 25°C…+70°C; Insulation resistance: >20 MΩ 500 Vdc, between electronics and housing; Short-circuit protection: YES; Reverse Polarity Protection: Yes; Housing material: ABS / PMMA.
The documented configuration includes Active Head Material: PMMA; Diameter/Dimension: Cubic; Short-circuit protection: Reverse Polarity Protection; Material: Housing material; Active Head Material: Storage temperature; >20 MΩ 500 Vdc, between electronics and housing: Contact resistance.
The documented configuration includes Function Principle: Polarized retroreflective; Functions: Polarized retroreflective; Application: Function Principle.
The documented configuration includes Connections: M12 plug; Interference to external light: according to EN 60947-5-2 : 2020; Contact resistance: 500 Vac 1 min., between electronics and housing; Shocks and vibrations: 0.5 mm amplitude, 10 … 55 Hz frequency, for every axis (EN60068-2-6); ≤2V@Iload: 100mA.
| Feature | Specification |
|---|---|
| Output voltage drop | ≤2V@Iload=100mA |
| Output type | NPN / PNP |
| Response time | 0,5 |
| Operating Voltage | 10…30VDC |
| Dimensions | 18x50x50 |
| Connections | M12 plug |
| Storage temperature | - 25°C…+70°C |
| Mechanical Protection | IP67 |
| Storage temperature | 25°C…+70°C |
| Nominal sensing distance | 8m |
| No-Load supply current | ≤ 30mA |
| Load current | ≤100mA |
| Interference to external light | according to EN 60947-5-2 : 2020 |
| Insulation resistance | >20 MΩ 500 Vdc, between electronics and housing |
| Contact resistance | 500 Vac 1 min., between electronics and housing |
| Shocks and vibrations | 0.5 mm amplitude, 10 … 55 Hz frequency, for every axis (EN60068-2-6) |
| ≤2V@Iload | 100mA |
| Impulsive Overvoltage Protection | Yes |
| Impulsive Overvoltage Protection | Insulation resistance |
| Short-circuit protection | YES |
| Reverse Polarity Protection | Yes |
| Housing material | ABS / PMMA |
| Active Head Material | PMMA |
| Diameter/Dimension | Cubic |
| Output type | Response time |
| Short-circuit protection | Reverse Polarity Protection |
| Material | Housing material |
| Active Head Material | Storage temperature |
| Function Principle | Polarized retroreflective |
| Functions | Polarized retroreflective |
| Emission | LED Red |
| Application | Function Principle |
| >20 MΩ 500 Vdc, between electronics and housing | Contact resistance |
