The S60-PA-2-F01-NN is a compact photoelectric sensor receiver from the Datasensing S60 series, designed for reliable through-beam object detection in industrial automation applications. The receiver is paired with the corresponding S60 emitter to create a through-beam sensing system capable of detecting objects across distances of up to 20 m.
The sensor provides an operating distance of 0 to 20 m, making it suitable for applications where a longer sensing distance and stable detection are required. Through-beam sensing provides reliable detection by monitoring interruption of the optical beam between the emitter and receiver.
The S60-PA-2-F01-NN features an NPN output with selectable normally open and normally closed operating modes. The output supports loads up to 100 mA and provides a fast 1 ms response time with a switching frequency of up to 500 Hz.
The sensor uses a compact 50 × 50 × 15 mm housing made from ABS, with a PMMA optical window. Its IP67 mechanical protection rating provides resistance against dust and water ingress, making the sensor suitable for demanding industrial environments.
This version uses a 2 m cable with a Ø4 mm cable diameter, providing a straightforward connection for machine installation. The sensor operates from a 10 to 30 VDC supply and incorporates electrical protection features including reverse-polarity protection and overload/short-circuit protection.
The S60-PA-2-F01-NN is suitable for automatic machines, packaging equipment, transportation systems, automated warehouses and general material-handling applications requiring dependable through-beam photoelectric detection.
| Product Family | S60 |
|---|---|
| Model | S60-PA-2-F01-NN |
| Order Code | 956201490 |
| Sensor Type | Compact photoelectric sensor |
| Optic Function | Through-beam receiver |
| Operating Distance | 0 ... 20 m |
| Light Emission | LED |
| Output Type | NPN, NO and NC |
| Output Current | ≤100 mA |
| Saturation Voltage | ≤2 V |
| Response Time | 1 ms |
| Switching Frequency | 500 Hz |
| Operating Mode | Dark on NO / Light on NC |
| Power Supply | 10 ... 30 VDC |
| Current Consumption | ≤35 mA |
| Connection | 2 m cable, Ø4 mm |
| Housing Material | ABS |
| Lens Material | PMMA window |
| Protection Rating | IP67 |
| Electrical Protection | Class 2 |
| Protection Devices | Reverse polarity; overload and short-circuit protection |
| Dimensions | 50 × 50 × 15 mm |
| Weight | ≤90 g |
| Operating Temperature | -25 ... +55 °C |
| Storage Temperature | -25 ... +70 °C |
| Reference Standard | EN 60947-5-2 |
