Explore performance details, construction highlights, applications, and technical information in one clear overview.
It uses Through-beam sensing. The nominal sensing distance is 8 m.
The sensing principle is Through-beam. Its Axial optical arrangement is paired with a nominal sensing distance of 8 m.
The optical emission is Red (660 nm). A switching frequency of 500 Hz.
The operating voltage is 10,8-30 VDC, with load current of ≤ 300 mA. Maximum ripple is ≤ 10%.
Short-circuit protection is Yes. Reverse polarity protection is Yes. Ingress protection is rated IP65.
Dimensions are 15x23x90 and the connection is M8 Connector. Weight is 70 g.
The operating temperature range is - 25 °C…+ 70 °C (Non-freezing). EMC compatibility is EN 60947-5-2.
The manufacturer part number is QXX/00-1F. This model is manufactured by M.D. Micro Detectors. Axial is Operating principle:.
Time to availability is 200 ms. The external-light interference limit is 3000 lx Incandescent lamp, 10000 lx.
QXX/00-1F uses Through-beam sensing with a nominal sensing distance of 8 m. For electrical integration, it provides operating voltage 10,8-30 VDC, switching frequency 500 Hz. The physical configuration includes dimensions 15x23x90, M8 Connector connection. It is rated IP65 for an operating temperature range of - 25 °C…+ 70 °C (Non-freezing).
| Specification | Details |
|---|---|
| Model | QXX/00-1F |
| Manufacturer part number | QXX/00-1F |
| Manufacturer | M.D. Micro Detectors |
| Switching frequency | 500 Hz |
| Weight | 70 g |
| Operating temperature | - 25 °C…+ 70 °C (Non-freezing) |
| Dimensions | 15x23x90 |
| Connection | M8 Connector |
| Optical position | Axial |
| Operating principle | Through-beam |
| Nominal sensing distance | 8 m |
| Repeat accuracy | ≤ 5% |
| Degree of protection | IP65 |
| EMC compatibility | EN 60947-5-2 |
| Time to availability | 200 ms |
| Short-circuit protection | Yes |
| Reverse polarity protection | Yes |
| Maximum ripple | ≤ 10% |
| External light interference | 3000 lx Incandescent lamp, 10000 lx |
| Operating voltage | 10,8-30 VDC |
| Load current | ≤ 300 mA |
| Leakage current | ≤ 100 µA @ 30 VDC |
| Emission | Red (660 nm) |
