Explore performance details, construction highlights, applications, and technical information in one clear overview.
It features a diaphragm construction, operates within a 0.2-2 bar adjustment range, and supports up to 350 bar static pressure. This pressure switch delivers reliable performance with a 220 VAC working voltage, 3 A resistive current capacity, and IP65 protection for harsh environments.
This diaphragm-type pressure switch operates within a 0.2-2 bar adjustment range and is rated for up to 350 bar static pressure, ensuring reliable performance in high-pressure systems. With a 220 VAC working voltage, 3 A resistive current capacity, and IP65 protection, it provides exceptional durability and safety in industrial settings where precise pressure control is critical.
It features a diaphragm construction with a 0.2-2 bar adjustment range (±0.2 tolerance) and a maximum static pressure rating of 350 bar. The switch includes a fixed hysteresis of 30% of the set-point (or 10% F.S.) at 25°C and is rated for 100 cycles per minute. It also offers IP65 protection for dust and water resistance, ensuring reliable operation in harsh industrial environments.
This pressure switch functions optimally at 25°C with a maximum fixed hysteresis of 30% of the set-point (or 10% F.S.). The PMC10DFC14KHSGSM- Pressure switch with SPDT contacts is designed for use with 220 VAC power supply and can handle up to 3 A resistive current loads. It is suitable for applications requiring precise pressure monitoring where environmental protection is essential, such as in industrial fluid systems and pneumatic networks.
This design ensures durability and resistance to corrosion in industrial settings. The PMC10DFC14KHSGSM- Pressure switch with SPDT contacts is rated for IP65 protection, providing effective shielding against dust and water ingress, making it ideal for use in environments where contamination is a concern.
The ELETTROTEC PMC10DFC14KHSGSM- Pressure switch with SPDT contacts- Pressure switch with SPDT contacts is an industrial Pressure. Selection should be based on the documented characteristics and the requirements of the intended application.
| Feature | Specification |
|---|---|
| Maximum voltage 250 Vac, 24 Vdc; 30 V with option “G” | Max. voltage 250 Vac, 24 Vdc; 30 V with “G” option |
| Working voltage 220 Vac | Working voltage 220 Vac |
| Current intensity 3 A (resistive), 2 A (inductive) | Current 3 A (resistive), 2 A (inductive) |
| Fixed differential max. 25°C 30% of the set-point value di set-point (o 10% F.S.) | Max. fixed hysteresis at 25°C 30% of set-point (or 10% F.S.) |
| Current maximum / Max. current | < 30 mA |
