The IFM O5D100 is a laser distance sensor with a 0.03...2 m measuring range. It uses PMD time-of-flight technology for reliable background-suppressed distance measurement. The sensor provides complementary PNP outputs and IO-Link communication. A three-digit display and pushbuttons simplify local setup. IP65/IP67 protection and a compact rectangular housing support industrial automation.
Explore performance details, construction highlights, applications, and technical information in one clear overview.
The O5D100 measures distances from 0.03 to 2 m. Its background suppression extends up to 20 m. The red 650 nm laser provides a visible reference for alignment. The maximum light-spot diameter is below 5 mm at 2 m. These characteristics support reliable object and position detection.
The sensor includes a three-digit alphanumeric display. Range-plus and range-minus buttons provide direct switching-point adjustment. The display shows measured distance during operation. Yellow and green LEDs provide switching and operating status. This simplifies installation and maintenance.
The O5D100 supports IO-Link 1.1 with COM2 communication at 38.4 kBaud. Process data and diagnostic information can be exchanged with the controller. SIO mode is available for conventional switching operation. The sensor provides analogue and binary process data. This makes it suitable for connected factory automation.
0.03...2 m range
PMD time-of-flight technology
Red 650 nm laser
Laser class 2
Background suppression up to 20 m
PNP outputs
Complementary switching
Three-digit display
Pushbuttons
IO-Link 1.1
COM2 38.4 kBaud
M12 connector
IP65/IP67
10...30 V DC
100 mA output
Object detection
Distance measurement
Conveyor systems
Packaging machines
Material handling
Position monitoring
Factory automation
Assembly machines
Production lines
Machine control
The O5D100 provides both distance measurement and switching control. The display allows operators to configure the sensor without external software. Background suppression improves detection stability. IO-Link provides additional digital configuration and diagnostics. This combination simplifies machine commissioning.
| Specification | O5D100 |
|---|---|
| Product Type | Photoelectric distance sensor |
| Model | O5D100 |
| Product Code | O5DLCPKG/US |
| Measuring Range | 0.03...2 m |
| Background Suppression | Up to 20 m |
| Light Type | Red light |
| Wavelength | 650 nm |
| Laser Class | 2 |
| Light Spot | <5 mm at 2 m |
| Sampling Rate | 33 Hz |
| Electrical Design | PNP |
| Output Function | NO/NC complementary |
| Digital Outputs | 2 |
| Output Current | 2 × 100 mA |
| Supply Voltage | 10...30 V DC |
| Current Consumption | <75 mA at 24 V |
| Protection Class | III |
| Reverse Polarity | Yes |
| Short-Circuit Protection | Yes |
| Overload Protection | Yes |
| Communication | IO-Link |
| IO-Link Revision | 1.1 |
| Transmission | COM2, 38.4 kBaud |
| SIO Mode | Yes |
| Display | 3-digit alphanumeric |
| Connection | M12 |
| Housing | PA |
| Bezel | Stainless steel |
| Lens | PMMA |
| Protection | IP65/IP67 |
| Ambient Temperature | -25...60 °C |
