The ELETTROTEC PDE2LBVE1H- Differential pressure switch -Clogging indicator- Differential pressure switch -Clogging indicator is a precision instrument for monitoring fluid flow clogging in industrial systems. This pressure switch features a robust brass body with HNBR diaphragm/seal material, operating within a temperature range of -25°C to +140°C. It offers switch ratings of 1 A / 220 Vac, 3 A / 24 Vdc, and 7 A / 250Vac, with set points adjustable between 2 bar and 8 bar for precise clogging detection in high-pressure applications up to 450 bar.
The ELETTROTEC PDE2LBVE1H- Differential pressure switch -Clogging indicator- Differential pressure switch -Clogging indicator is a specialized pressure monitoring device designed to detect clogging events in industrial fluid systems. This switch utilizes a differential pressure mechanism to identify when flow restrictions occur, providing critical operational feedback without requiring continuous flow measurement. Its robust construction with a brass body and HNBR diaphragm/seal material ensures reliable performance across extreme temperature ranges (-25°C to +140°C) and high-pressure environments (up to 450 bar). The switch operates with precise set points adjustable between 2 bar and 8 bar, featuring a fixed differential of 30% of the set-point value for accurate clogging indication.
The PDE2LBVE1H- functions by measuring the difference between upstream and downstream fluid pressure. When the differential pressure reaches the set point, the switch activates, indicating potential clogging in the system. This mechanism allows for early detection of flow restrictions without interrupting the process, making it ideal for continuous monitoring in critical industrial applications.
The switch operates within a temperature range of -25°C to +140°C, depending on the diaphragm/seal material. It supports a maximum static pressure of 450 bar and features a fixed differential of 30% of the set-point value. The PDE2LBVE1H- Differential pressure switch -Clogging indicator is rated for 1 A / 220 Vac, 3 A / 24 Vdc, and 7 A / 250Vac, with set points adjustable between 2 bar and 8 bar (±10% tolerance).
The PDE2LBVE1H- offers versatile connection options including G1/2" threads, M22 x 1.5, and M20 x 1.5 metric threads, ensuring compatibility with a wide range of industrial piping systems and equipment.
Constructed from brass for durability and corrosion resistance, the switch incorporates HNBR diaphragm/seal material for reliable performance in high-temperature and high-pressure environments. This combination ensures long-term stability and resistance to process fluids.
The ELETTROTEC PDE2LBVE1H- Differential pressure switch -Clogging indicator- Differential pressure switch -Clogging indicator is an industrial Pressure. Selection should be based on the documented characteristics and the requirements of the intended application.
| Feature | Specification |
|---|---|
| Switch rating | 1 A / 220 Vac – 3 A / 24 Vdc – 7 A / 250Vac |
| Settings ΔP | 2 bar – 5 bar – 7 bar – 8 bar |
| Max. static pressure | 450 bar |
| temperature tange | -25 °C +140 °C (according to diaphragm/seal material) |
| Threads | G1/2″ – M22 x 1.5 – M20 x 1.5 |
| Diaphragm/ Seal material | HNBR – FKM |
