Explore performance details, construction highlights, applications, and technical information in one clear overview.
PSC/CP-0E is a miniaturized cubic retro-reflective photoelectric sensor for object presence and position detection. It uses retro-reflective as its sensing or measurement method. The specified operating range or reference distance is 3 m. The output is PNP, DO. The supply is 10…30 VDC. The connection is Connector. The housing is ABS.
The optical function is Retro-reflective. The sensing distance is 3 m. Emission is Infrared, 880 nm. The Adjustment is 1-turn sensitivity trimmer.
The specified value of 3 m gives the reference distance or measurement envelope for the device. The retro-reflective arrangement determines how the device responds to the target or measures distance.
The supply is 10…30 VDC. The output is PNP, DO. The maximum load current is 100 mA max. The switching frequency is 100 Hz.
The supply of 10…30 VDC defines the required operating voltage. The PNP, DO output defines the switching or signal arrangement. The switching frequency is 100 Hz.
The housing is ABS. The connection is Connector. Protection is rated IP65. The operating temperature range is -25…+70 °C.
The ABS housing provides the specified mechanical format. The Connector connection provides the stated physical interface. Protection is rated IP65. The operating temperature range is -25…+70 °C.
PSC/CP-0E combines the miniaturized cubic retro-reflective photoelectric sensor characteristics given in the product specification. The sensor type is Miniaturized cubic retro-reflective photoelectric sensor. The optical function is Retro-reflective. The sensing distance is 3 m. The output is PNP, DO. The supply is 10…30 VDC. The connection is Connector. These technical values describe the sensing, electrical and mechanical properties of PSC/CP-0E.
| Specification | Value |
|---|---|
| Model | PSC/CP-0E |
| Sensor type | Miniaturized cubic retro-reflective photoelectric sensor |
| Optical function | Retro-reflective |
| Nominal sensing distance | 3 m |
| Output | PNP, DO |
| Connection | Connector |
| Supply voltage | 10…30 VDC |
| Load current | 100 mA max. |
| Switching frequency | 100 Hz |
| Operating temperature | -25…+70 °C |
| Protection | IP65 |
| Emission | Infrared, 880 nm |
| Adjustment | 1-turn sensitivity trimmer |
| Housing | ABS |
| Optics | PMMA |
