The nominal sensing distance is 100 mm.
Its Axial optical arrangement is paired with a nominal sensing distance of 100 mm. The optical emission is Infrared (880 nm).
A switching frequency of 100 Hz. The thermal drift Sr is ≤ 10% Sr, with repeat accuracy of ≤ 5%.
The output type is NPN. The output function is No.
The operating voltage is 10-30 VDC, with load current of ≤ 100 mA. Maximum ripple is ≤ 10%.
Short-circuit protection is Yes. Reverse polarity protection is Yes. Ingress protection is rated IP65.
Dimensions are 15x49x26 mm. Weight is 90 g.
The operating temperature range is - 25 °C…+ 70 °C (Non-freezing). EMC compatibility is EN 60947-5-2.
The manufacturer part number is PS2/AN-0E. This model is manufactured by M.D. Micro Detectors. Axial is Operating principle:.
Time to availability is 200 ms. The external-light interference limit is 3000 lx Incandescent lamp, 10000 lx.
For electrical integration, it provides output type NPN, operating voltage 10-30 VDC, switching frequency 100 Hz. The physical configuration includes dimensions 15x49x26 mm. It is rated IP65 for an operating temperature range of - 25 °C…+ 70 °C (Non-freezing).
| Specification | Details |
|---|---|
| Model | PS2/AN-0E |
| Manufacturer part number | PS2/AN-0E |
| Manufacturer | M.D. Micro Detectors |
| Output type | NPN |
| Output function | No |
| Switching frequency | 100 Hz |
| Weight | 90 g |
| Active head material | PMMA |
| Operating temperature | - 25 °C…+ 70 °C (Non-freezing) |
| Dimensions | 15x49x26 mm |
| Optical position | Axial |
| Nominal sensing distance | 100 mm |
| Thermal drift Sr | ≤ 10% Sr |
| Repeat accuracy | ≤ 5% |
| Degree of protection | IP65 |
| EMC compatibility | EN 60947-5-2 |
| Time to availability | 200 ms |
| Short-circuit protection | Yes |
| Reverse polarity protection | Yes |
| Maximum ripple | ≤ 10% |
| External light interference | 3000 lx Incandescent lamp, 10000 lx |
| Operating voltage | 10-30 VDC |
| Load current | ≤ 100 mA |
| Leakage current | ≤ 10 µA @ Vmax |
| Emission | Infrared (880 nm) |
