The IFM MFS201 is a cylindrical magnetic sensor with a 60 mm sensing range. It uses a PNP switching output and a 2 m cable for direct machine connection. The high-grade stainless-steel housing provides durable industrial construction. A 5000 Hz switching frequency supports rapid position detection. IP67 protection allows reliable use in general industrial environments.
Explore performance details, construction highlights, applications, and technical information in one clear overview.
The MFS201 detects magnetic actuators without mechanical contact. Its 60 mm sensing range provides flexible mounting between the sensor and actuator. The sensor is intended for position monitoring in industrial machinery. Magnetic switching provides repeatable operation during repeated machine cycles. This makes it suitable for automation equipment.
The sensor operates from 10...30 V DC. Its PNP output supports up to 200 mA switching current. The 5000 Hz switching frequency allows fast response to actuator movement. Short-circuit and overload protection improve operational reliability. The 3-wire connection simplifies integration with control systems.
The MFS201 uses a high-grade stainless-steel cylindrical housing. Its M12 × 1 / 50 mm configuration provides compact installation. The sensor is supplied with a 2 m cable. IP67 protection provides resistance against dust and water exposure. This makes the model suitable for demanding machine environments.
60 mm sensing range
PNP output
Normally open switching
10...30 V DC
5000 Hz switching frequency
200 mA output current
High-grade stainless-steel housing
M12 × 1 body
50 mm length
2 m cable
IP67 protection
Short-circuit protection
Overload protection
Yellow LED
3-wire connection
Cylinder position monitoring
Machine automation
Actuator detection
Conveyor systems
Machine tools
Production equipment
Packaging machinery
Material handling
Industrial automation
End-position detection
The 5000 Hz switching capability supports rapid magnetic position changes. This is useful for machines with repetitive actuator movement. The non-contact principle reduces mechanical wear. The PNP output provides direct switching information to suitable controllers. The sensor therefore supports efficient machine sequencing.
The stainless-steel housing provides mechanical durability for industrial installations. IP67 protection helps protect the sensor from dust and water. The 2 m cable simplifies installation where a connectorized solution is not required. The cylindrical body supports conventional threaded mounting. This provides a practical magnetic position sensor for automation.
| Specification | MFS201 |
|---|---|
| Product Type | Magnetic sensor |
| Model | MFS201 |
| Sensing Principle | Magnetic field |
| Electrical Design | PNP |
| Output Function | Normally open |
| Sensing Range | 60 mm |
| Supply Voltage | 10...30 V DC |
| Current Consumption | <10 mA |
| Protection Class | III |
| Reverse Polarity | Yes |
| Voltage Drop | 2.5 V |
| Output Current | 200 mA |
| Switching Frequency | 5000 Hz |
| Short-Circuit Protection | Yes |
| Overload Protection | Yes |
| Hysteresis | 1...10% |
| Housing Type | Cylindrical |
| Housing Material | High-grade stainless steel |
| Dimensions | M12 / L=50 mm |
| Installation | Threaded |
| Cable Length | 2 m |
| Cable Type | Industrial sensor cable |
| Connection | Cable |
| Wiring | 3-wire |
| Protection Rating | IP67 |
| Status Indication | LED |
| Detection Type | Non-contact |
| Target | Magnetic actuator |
| Typical Application | Position detection |
| Switching Technology | Magnetic |
| Switching Speed | High-speed 5000 Hz |
