A switching frequency of 160 Hz.
The output type is PNP,NPN. No-load supply current is 35 mA.
Maximum ripple is 5Vpp. Short-circuit protection is Yes. Reverse polarity protection is Yes. Surge protection is Yes.
Ingress protection is rated IP67.
Dimensions are 20x44,9x60 mm and the connection is 2 m PVC Cable. Weight is 160 g.
The operating temperature range is -25 °C…+55 °C. EMC compatibility is EN 60947-5-2.
The manufacturer part number is FGRW/0P-0A. This model is manufactured by M.D. Micro Detectors. Axial is Operating principle:.
For electrical integration, it provides output type PNP,NPN, switching frequency 160 Hz. The physical configuration includes dimensions 20x44,9x60 mm, 2 m PVC Cable connection. It is rated IP67 for an operating temperature range of -25 °C…+55 °C.
| Specification | Details |
|---|---|
| Model | FGRW/0P-0A |
| Manufacturer part number | FGRW/0P-0A |
| Manufacturer | M.D. Micro Detectors |
| Output type | PNP,NPN |
| Switching frequency | 160 Hz |
| Weight | 160 g |
| Active head material | PMMA |
| Operating temperature | -25 °C…+55 °C |
| Dimensions | 20x44,9x60 mm |
| Connection | 2 m PVC Cable |
| Optical position | Axial |
| Degree of protection | IP67 |
| EMC compatibility | EN 60947-5-2 |
| Short-circuit protection | Yes |
| Reverse polarity protection | Yes |
| Surge protection | Yes |
| Maximum ripple | 5Vpp |
| Load current | ≤ 100 mA |
| No-load supply current | 35 mA |
