It uses Polarized sensing.
The sensing principle is Polarized. A switching frequency of 33 Hz.
The operating voltage is 24..240 VAC/24…240Vcc. No-load supply current is ≤ 2VA.
Short-circuit protection is Yes. Reverse polarity protection is Yes. Surge protection is Yes. Ingress protection is rated IP67.
Dimensions are 20x44,9x60 mm and the connection is 2 m PVC Cable. Weight is 160 g.
The operating temperature range is -25 °C…+55 °C. EMC compatibility is EN 60947-5-2.
The manufacturer part number is FGRN/DT-0A. This model is manufactured by M.D. Micro Detectors. Axial is Operating principle:.
External-light interference is limited to 3,000 lx (Incandescent lamp), 10,000 (Sunlight).
FGRN/DT-0A uses Polarized sensing. For electrical integration, it provides operating voltage 24..240 VAC/24…240Vcc, switching frequency 33 Hz. The physical configuration includes dimensions 20x44,9x60 mm, 2 m PVC Cable connection. It is rated IP67 for an operating temperature range of -25 °C…+55 °C.
| Specification | Details |
|---|---|
| Model | FGRN/DT-0A |
| Manufacturer part number | FGRN/DT-0A |
| Manufacturer | M.D. Micro Detectors |
| Switching frequency | 33 Hz |
| Weight | 160 g |
| Active head material | PMMA |
| Operating temperature | -25 °C…+55 °C |
| Dimensions | 20x44,9x60 mm |
| Connection | 2 m PVC Cable |
| Optical position | Axial |
| Operating principle | Polarized |
| Degree of protection | IP67 |
| EMC compatibility | EN 60947-5-2 |
| Short-circuit protection | Yes |
| Reverse polarity protection | Yes |
| Surge protection | Yes |
| External light interference | 3,000 lx (Incandescent lamp), 10,000 (Sunlight) |
| Operating voltage | 24..240 VAC/24…240Vcc |
| No-load supply current | ≤ 2VA |
