The nominal sensing distance is 50 m.
The nominal sensing distance is 50 m. A switching frequency of 1 kHz.
The output type is PNP. No-load supply current is ≤ 35 mA (Emitter), ≤ 20 mA (Receiver).
Maximum ripple is 5Vpp. Reverse polarity protection is Yes. Surge protection is Yes.
Ingress protection is rated IP67.
Dimensions are 20x44,9x60 mm. Weight is 80 g.
The operating temperature range is -25 °C…+55 °C. EMC compatibility is EN 60947-5-2.
The manufacturer part number is FGRHD/0P-0E. This model is manufactured by M.D. Micro Detectors.
| Specification | Details |
|---|---|
| Model | FGRHD/0P-0E |
| Manufacturer part number | FGRHD/0P-0E |
| Manufacturer | M.D. Micro Detectors |
| Output type | PNP |
| Switching frequency | 1 kHz |
| Weight | 80 g |
| Active head material | PMMA |
| Operating temperature | -25 °C…+55 °C |
| Dimensions | 20x44,9x60 mm |
| Nominal sensing distance | 50 m |
| Degree of protection | IP67 |
| EMC compatibility | EN 60947-5-2 |
| Reverse polarity protection | Yes |
| Surge protection | Yes |
| Maximum ripple | 5Vpp |
| Load current | ≤ 100 mA (Receiver) |
| No-load supply current | ≤ 35 mA (Emitter), ≤ 20 mA (Receiver) |
