It uses Through-beam sensing. The unit serves as the emitter in the optical pair. The nominal sensing distance is 20 m.
The QMRH/00-0A uses Through-beam sensing and is configured as the emitter in the optical pair. The nominal sensing distance is 20 m.
The optical emission is Red (630 nm).
The operating voltage is 10-30 VDC. No-load supply current is ≤30 mA.
Maximum ripple is 10%. Short-circuit protection is Yes. Reverse polarity protection is Yes. Surge protection is Yes.
Ingress protection is rated IP67.
LED indicators is Yellow (Power ON).
The housing is PA66, while the active head uses PMMA. Dimensions are 31,2x21x13 mm and the connection is 2 m PVC Cable.
Weight is 52 g.
Tightening torque is 1 nm.
The operating temperature range is - 25 °C…+ 70° C (Non-freezing). EMC compatibility is EN 60947-5-2.
Storage temperature is - 30 °C…+ 80° C (Non-freezing).
The manufacturer part number is QMRH/00-0A. This model is manufactured by M.D. Micro Detectors. Time to availability is ≤200 ms.
QMRH/00-0A uses Through-beam sensing as the emitter in the optical pair, with a nominal sensing distance of 20 m. For electrical integration, it provides operating voltage 10-30 VDC. The physical configuration includes PA66 housing, dimensions 31,2x21x13 mm, 2 m PVC Cable connection. It is rated IP67 for an operating temperature range of - 25 °C…+ 70° C (Non-freezing).
| Specification | Details |
|---|---|
| Model | QMRH/00-0A |
| Manufacturer part number | QMRH/00-0A |
| Manufacturer | M.D. Micro Detectors |
| Weight | 52 g |
| Active head material | PMMA |
| Housing material | PA66 |
| Tightening torque | 1 nm |
| Operating temperature | - 25 °C…+ 70° C (Non-freezing) |
| Dimensions | 31,2x21x13 mm |
| Connection | 2 m PVC Cable |
| Storage temperature | - 30 °C…+ 80° C (Non-freezing) |
| Emitter/receiver | Emitter |
| Operating principle | Through-beam |
| Nominal sensing distance | 20 m |
| Repeat accuracy | 5% |
| Degree of protection | IP67 |
| EMC compatibility | EN 60947-5-2 |
| Time to availability | ≤200 ms |
| Short-circuit protection | Yes |
| Reverse polarity protection | Yes |
| Surge protection | Yes |
| Maximum ripple | 10% |
| Operating voltage | 10-30 VDC |
| LED indicators | Yellow (Power ON) |
| No-load supply current | ≤30 mA |
| Emission | Red (630 nm) |
