The AS1-LD-SR-010-J - photoelectric sensor is a industrial product from Datasensing. The documented values above identify the exact configuration and are the basis for technical selection and system integration.
The Datasensing AS1-LD-SR-010-J is a cross-beam photoelectric sensor designed for industrial applications. It features a PNP output in dark mode, ensuring reliable detection with minimal electrical interference.
Engineers and technicians select this sensor for critical detection tasks where precise timing and environmental resilience are essential. Its robust construction and fast response ensure consistent performance in demanding industrial settings.
The documented configuration includes Response time: 1,7ms; Nominal sensing distance: 0,3…2m; Emission: Infrared (880nm).
The documented configuration includes Output voltage drop: ≤1,5V Iload = 100mA; Output type: PNP - Dark mode; Operating Voltage: 20,4…27,6VDC; No-Load supply current: ≤190mA; Load current: ≤100mA; Output Function: Dark ON; Output type: Output Function.
The documented configuration includes Dimensions: 22x150x43; Weight: 300g; Operating Temperature: 0°C…+ 50° C; Mechanical Protection: IP65; controlled height: 100mm; Material: Metal - Aluminium / PMMA; Housing material: Aluminium; Active Head Material: PMMA.
The documented configuration includes Material: Housing material.
The documented configuration includes Function Principle: Emitter- Receiver; Functions: Light array for detection; Application: Function Principle.
The documented configuration includes Connections: M12 Plug; minimum detectable object: Flat: 0,2x200mm Cylindrical: Ø18mm; Description: Slim profile - Low res. 18 mm; Flat: 0,2x200mm Cylindrical: Ø18mm; ≤1,5V Iload: 100mA; Connections: Connector.
| Feature | Specification |
|---|---|
| Output voltage drop | ≤1,5V Iload = 100mA |
| Output type | PNP - Dark mode |
| Response time | 1,7ms |
| Operating Voltage | 20,4…27,6VDC |
| Dimensions | 22x150x43 |
| Weight | 300g |
| Connections | M12 Plug |
| Operating Temperature | 0°C…+ 50° C |
| Mechanical Protection | IP65 |
| Nominal sensing distance | 0,3…2m |
| controlled height | 100mm |
| minimum detectable object | Flat: 0,2x200mm Cylindrical: Ø18mm |
| Description | Slim profile - Low res. 18 mm |
| No-Load supply current | ≤190mA |
| Load current | ≤100mA |
| Emission | Infrared (880nm) |
| Flat | 0,2x200mm Cylindrical: Ø18mm |
| ≤1,5V Iload | 100mA |
| Output Function | Dark ON |
| Material | Metal - Aluminium / PMMA |
| Housing material | Aluminium |
| Active Head Material | PMMA |
| Output type | Output Function |
| Material | Housing material |
| Connections | Connector |
| Function Principle | Emitter- Receiver |
| Functions | Light array for detection |
| Application | Function Principle |
