The IFM VSA201 is a high-range single-axis MEMS acceleration sensor for industrial vibration detection. It measures -250 to +250 g across a 1–6,000 Hz frequency range. The sensor provides a 0–10 mA analogue output and uses an M8 × 1.25 mounting interface. Its 316L stainless-steel housing provides IP67/IP68/IP69K protection and high mechanical durability. An M12 A-coded connector provides the electrical interface to external VSE diagnostic electronics.
Explore performance details, construction highlights, applications, and technical information in one clear overview.
The VSA201 provides a ±250 g vibration measurement range. This gives it a significantly higher acceleration range than the ±25 g VSA models. Its 1–6,000 Hz frequency range supports vibration detection across industrial machinery. The capacitive MEMS principle provides single-axis measurement. This makes the VSA201 suitable for high-vibration environments.
The sensor provides a 0–10 mA analogue output for external diagnostic electronics. It operates from 7.2–10.8 V DC. The M12 connector provides a defined interface for compatible connection cables. Reverse-polarity protection is included. This allows the sensor to operate as part of an IFM VSE vibration-monitoring system.
The VSA201 uses a cylindrical 316L stainless-steel housing. Its M8 × 1.25 mounting interface is tightened to 8 Nm. The sensor measures approximately Ø17 × 53 mm and weighs 49 g. IP67/IP68/IP69K protection provides strong environmental protection. The supplied conical washer supports proper mechanical installation.
High-range acceleration sensor
MEMS technology
Single-axis measurement
Capacitive principle
-250…250 g range
1…6,000 Hz frequency range
14.2 µA/g sensitivity
0–10 mA output
300 Ω maximum load
7.2…10.8 V DC
<15 mA consumption
M8 × 1.25 mounting
8 Nm tightening torque
316L stainless-steel housing
Ø17 × 53 mm dimensions
49 g weight
IP67/IP68/IP69K
M12 A-coded connector
500 g mechanical overload
High-vibration machinery
Motor monitoring
Gearbox diagnostics
Heavy rotating equipment
Machine condition monitoring
Industrial vibration analysis
Predictive maintenance
VSE diagnostic systems
Machine protection
Industrial automation
The ±250 g range allows the VSA201 to measure substantially higher vibration amplitudes. This makes it suitable for machinery where lower-range accelerometers may not provide sufficient measurement capacity. The 6 kHz frequency range supports detailed vibration monitoring. Single-axis sensing provides a defined measurement direction. This makes the sensor useful for heavy industrial equipment.
The M8 × 1.25 interface provides secure machine mounting. Stainless steel 316L provides strong mechanical durability. The supplied conical washer supports correct installation. The 8 Nm tightening torque provides the specified mounting condition. IP67/IP68/IP69K protection supports industrial environmental exposure.
| Specification | VSA201 Details |
|---|---|
| Product | Acceleration sensor |
| Order number | VSA201 |
| Product designation | VIBRATION SENSOR |
| Sensor technology | MEMS |
| Measuring principle | Capacitive |
| Measurement axes | 1 |
| Vibration range | -250…250 g |
| Frequency range | 1…6,000 Hz |
| Sensitivity | 14.2 µA/g |
| Linearity deviation | 5% |
| Analogue output | 0…10 mA |
| Maximum load | 300 Ω |
| Supply voltage | 7.2…10.8 V DC |
| Current consumption | <15 mA |
| Insulation resistance | 100 MΩ |
| Protection class | III |
| Reverse-polarity protection | Yes |
| Ambient temperature | -30…125°C |
| UL temperature | <70°C |
| Storage temperature | -30…125°C |
| Protection | IP67/IP68/IP69K |
| Housing | Cylindrical |
| Housing material | Stainless steel 316L |
| Mounting | M8 × 1.25 |
| Tightening torque | 8 Nm |
| Dimensions | Ø17 × 53 mm |
| Weight | 49 g |
| Connection | M12 A-coded |
| Mechanical overload | 500 g |
