The Vacuum Filter VFB is a specialized component designed to remove dust and water droplets from the air stream as it is sucked in by a vacuum generator. By leveraging the element and cyclone effect, it efficiently separates particulate matter and liquid droplets, ensuring clean, dry airflow for downstream processes or equipment.
The filter body is constructed using PBT resin for its main structural components, a material well-suited for general environmental conditions. Critical metal parts, such as the housing and fittings, are made from brass with electroless nickel plating to enhance durability and corrosion resistance. The sealing elements are fabricated from NBR rubber, which provides reliable sealing performance under typical operating conditions.
The VFB features a large capacity union-type connection designed specifically for integration into vacuum circuits. This configuration allows for secure, leak-free attachment to vacuum generators or piping systems, ensuring stable and consistent operation within the vacuum system.
The filter is rated for use with air as the fluid medium. It operates within a pressure range of -100 to 0 kPa and is suitable for ambient temperatures between 0°C and 60°C. The unit is not designed for use in freezing conditions, as operation below 0°C may cause damage or performance issues.
The Vacuum Filter VFB is available in a standard configuration with no color options or variant sizes specified. It is designed to fit within standard vacuum circuit systems and is compatible with union-type connections of common dimensions, though specific size details are not provided in the product data.
Installation requires connecting the filter directly into the vacuum circuit using the large capacity union-type interface. The filter can be integrated between the vacuum generator and downstream equipment, ensuring that incoming air is filtered before reaching sensitive components.
| Specification | Details |
|---|---|
| Fluid medium | Air |
| Operating pressure range | -100 to 0 kPa |
| Operating temp. range | 0 to 60℃ (No freezing) |
| Main resin material | PBT |
| Main metal material | Brass with electroless nickel plating |
