Servo-controlled 3-way vacuum solenoid valves is a Vuototecnica vacuum-technology product designed for industrial vacuum handling and automated gripping. Key product details include Official Vuototecnica technical evidence: two-position, three-way vacuum solenoid valves with pneumatically servo-controlled conical shutters; normally closed or normally open. Anodised aluminium body, Vulkollan/HNBR shutters on stainless stem, servo membrane and spring. Operating pressure 0.5–3000 mbar absolute; servo-control pressure per table; fluid temperature -5 to +60°C. Standard coil plasticised, class F, IP54/IP65 with connector, ±10% voltage tolerance, max 20 VA AC / 18 W DC. Official table examples 07 01 11 and 07 02 11: G1/4 and G3/8, max flow 6 and 10 m³/h, vacuum range 1000–0.5 mbar, reaction 16/27 ms, passage 8.5/11.5 mm²-related table values, servo pressure 4–7 bar, weights 0.56/0.54 kg. Catalogue 4.22_4.27 / 4.26_4.31..
The published configuration provides the mechanical features needed for the intended vacuum-handling application. The listed construction details, connection arrangement and available configuration information describe how this product family is built and used within a vacuum system.
The technical characteristics above identify the principal construction, connection or application features published for this product. Where the range contains multiple article codes or configurations, dimensions and performance can vary by the selected version, so the applicable catalogue configuration should be matched to the required installation.
Servo-controlled 3-way vacuum solenoid valves is suitable for industrial vacuum gripping, pick-and-place, material handling and automated machine operations appropriate to the stated product configuration. Its construction and connection features support integration into vacuum handling equipment where the published characteristics meet the application requirements.
Installation should follow the published connection and mounting arrangement for the selected configuration. Match the holder, valve, fitting or accessory arrangement to the applicable article code and the requirements of the vacuum circuit.
For selection, compare the published construction, connection type, dimensions and other applicable technical characteristics with the required cup size, mounting arrangement and vacuum-handling duty. Use the exact article code where the family includes multiple configurations.
This product is intended to function as part of an industrial vacuum system. Correct compatibility depends on the selected configuration and its connection with vacuum cups, generators, valves, filters, fittings and other system components.
The technical characteristics for this listing are based on the corresponding official Vuototecnica product-family information, with the applicable product configuration and published details retained for product selection.
| Feature | Specification |
|---|---|
| Vacuum Range | Official Vuototecnica technical evidence: two-position, three-way vacuum solenoid valves with pneumatically servo-controlled conical shutters |
| Operating Pressure | normally closed or normally open. Anodised aluminium body, Vulkollan/HNBR shutters on stainless stem, servo membrane and spring. Operating pressure 0.5–3000 mbar absolute |
| Operating Pressure 2 | servo-control pressure per table |
| Operating Pressure 3 | fluid temperature -5 to +60°C. Standard coil plasticised, class F, IP54/IP65 with connector, ±10% voltage tolerance, max 20 VA AC / 18 W DC. Official table examples 07 01 11 and 07 02 11: G1/4 and G3/8, max flow 6 and 10 m³/h, vacuum range 1000–0.5 mbar, reaction 16/27 ms, passage 8.5/11.5 mm²-related table values, servo pressure 4–7 bar, weights 0.56/0.54 kg. Catalogue 4.22_4.27 / 4.26_4.31. |
