Product Overview

PR series is a Hanyoung NUX photoelectric sensor for non-contact detection and machine sensing. The configuration is defined by its sensing method, sensing range, output arrangement and electrical requirements, with model information of Me tal | NPN | PR- T10NC | PRM- M2N | PRM- R01N | PRM- R04N. Sensing mode: Through-beam | Retro reflective (mirror) | Diff use- reflective; Sensing distance: 10 m | 0.1 ~ 2mm (Note 1) | 0.1m | 0.4m; Hysteresis distance: - | Less than 20% of the sensing range; Control output: ▪NPN or PNP open collector output ▪Load current - max. 100 mA (26.4 V d.c. standard) ▪Residual voltage - NPN : max. 1 V, PNP : max. 1 V.

The sensing distance, target object, response time, output type and environmental limits are the key details to compare when selecting the sensor for a specific machine or detection point. Light source (Wavelength): Infrared ligtening LED (890 ㎚) | IR (860 nm); Display: PC; Operation mode: Light ON / Dark ON(By white cable) ※ but, through-beam has only in the receiver; Material: Case | ▪Metal : Brass Chrome Plating ▪Plastic : Plastic.

Key Features

Key strengths of the PR series come from the combination of its functional configuration and practical installation specifications. The following characteristics highlight the values that matter most when comparing the product with equipment requirements.

Sensing mode: Through-beam | Retro reflective (mirror) | Diff use- reflective; Sensing distance: 10 m | 0.1 ~ 2mm (Note 1) | 0.1m | 0.4m; Power voltage: 12 - 24 V d.c. ± 10 % (Ripple max. 10 %); Control output: ▪NPN or PNP open collector output ▪Load current - max. 100 mA (26.4 V d.c. standard) ▪Residual voltage - NPN : max. 1 V, PNP : max. 1 V; Response time: 1 ms or less.

• Sensing mode: Through-beam | Retro reflective (mirror) | Diff use- reflective
• Sensing distance: 10 m | 0.1 ~ 2mm (Note 1) | 0.1m | 0.4m
• Power voltage: 12 - 24 V d.c. ± 10 % (Ripple max. 10 %)
• Control output: ▪NPN or PNP open collector output ▪Load current - max. 100 mA (26.4 V d.c. standard) ▪Residual voltage - NPN : max. 1 V, PNP : max. 1 V
• Response time: 1 ms or less
• Degree of protection: IP66 (IEC standard)
• Light source (Wavelength): Infrared ligtening LED (890 ㎚) | IR (860 nm)

Technical Characteristics

The PR series technical profile is centred on sensing method, detection range, target characteristics, output behaviour and response time. These parameters define the sensor's operating window and electrical interface. Response time: 1 ms or less; Current consumption: Transmitter : 15 ㎃ Receiver : 20 ㎃ | Max. 30 mA; Power voltage: 12 - 24 V d.c. ± 10 % (Ripple max. 10 %); Protection circuit: Common | ▪Power reverse connection protection ▪Output reverse connection protection ▪Output short-circuit over-current protection ▪Output short-circuit alarm (Note2).

Additional technical characteristics include Insulation Resistance: More than 20 MΩ (500 V d.c. mega); Noise immunity: Square wave noise by noise simulator (pulse width 1㎲) ± 240 V; Dielectric strength: 1,000 V a.c. (50/60 Hz for 1 minute).

Design and Construction

The physical design of PR series should be considered together with the installation environment and the available mounting or display arrangement. Lens: PC; Weight: ▪Metal : Approx. 320g ▪Plastic : Approx. 280g | ▪Metal : Approx. 160g ▪Plastic : Approx. 140g; Vibration bresistance: 10 - 55 Hz, Double amplitude : 1.5 mm, X·Y·Z 2 in each direction for 2 hours; Shock resistance: 500 m/s², X·Y·Z each direction 3 times.

Further construction and environmental details include Ambient temperature: During operation : -25 ~ +55 ℃, During storage : -40 ~ +70 ℃ (Without condensation); Ambient humidity: 35 ~ 85 % RH (Without condensation); Degree of protection: IP66 (IEC standard).

Integration and Operation

Integration of PR series starts with matching its sensing method, supply voltage, output type and connection method to the control system. Sensing mode: Through-beam | Retro reflective (mirror) | Diff use- reflective; Sensing distance: 10 m | 0.1 ~ 2mm (Note 1) | 0.1m | 0.4m; Power voltage: 12 - 24 V d.c. ± 10 % (Ripple max. 10 %); Control output: ▪NPN or PNP open collector output ▪Load current - max. 100 mA (26.4 V d.c. standard) ▪Residual voltage - NPN : max. 1 V, PNP : max. 1 V.

Additional operating and interface details include Response time: 1 ms or less; Degree of protection: IP66 (IEC standard); Light source (Wavelength): Infrared ligtening LED (890 ㎚) | IR (860 nm). These values provide a practical reference for wiring, setup and normal operation within the selected configuration.

Selection and Use

Choose PR series by confirming the exact model or configuration against the required operating conditions. The available model information is Me tal | NPN | PR- T10NC | PRM- M2N | PRM- R01N | PRM- R04N. Model: Me tal | NPN | PR- T10NC | PRM- M2N | PRM- R01N | PRM- R04N; Sensing mode: Through-beam | Retro reflective (mirror) | Diff use- reflective; Sensing distance: 10 m | 0.1 ~ 2mm (Note 1) | 0.1m | 0.4m; Power voltage: 12 - 24 V d.c. ± 10 % (Ripple max. 10 %).

Before installation, confirm Control output: ▪NPN or PNP open collector output ▪Load current - max. 100 mA (26.4 V d.c. standard) ▪Residual voltage - NPN : max. 1 V, PNP : max. 1 V; Response time: 1 ms or less; Degree of protection: IP66 (IEC standard). Matching the model, electrical ratings, signal requirements, physical arrangement and environmental limits helps keep the product within its specified operating conditions.
