Product Overview

PLD series is a Hanyoung NUX photoelectric sensor for non-contact detection and machine sensing. The configuration is defined by its sensing method, sensing range, output arrangement and electrical requirements, with model information of PLD-R2N | PLD-R2P. Sensing Type: Diffuse - reflective; Sensing distance: 2m; Hysteresis: Within 20 % of detectable distance; Control output: • NPN open collector Max. 150 mA d.c. (resistance load) • Residual voltage: 1 V d.c. Below | • PNP open collector Max. 150 mA d.c. (resistance load) • Residual voltage: 1 V d.c. Below.

The sensing distance, target object, response time, output type and environmental limits are the key details to compare when selecting the sensor for a specific machine or detection point. Light source (wavelength): Infrared LED (850 nm); LED Indicator: • Control output : Red LED • Safety : green LED; Operation mode: Light On mode; Connection method: • Cable pull-out typed • Number of wires: 3P • Outer diameter: Ø3 ㎜ • Length: 2 m.

Key Features

Key strengths of the PLD series come from the combination of its functional configuration and practical installation specifications. The following characteristics highlight the values that matter most when comparing the product with equipment requirements.

Sensing Type: Diffuse - reflective; Sensing distance: 2m; Power voltage: 12 - 24 V d.c. ±10 %; Control output: • NPN open collector Max. 150 mA d.c. (resistance load) • Residual voltage: 1 V d.c. Below | • PNP open collector Max. 150 mA d.c. (resistance load) • Residual voltage: 1 V d.c. Below; Response time: Max. 1 ms.

• Sensing Type: Diffuse - reflective
• Sensing distance: 2m
• Power voltage: 12 - 24 V d.c. ±10 %
• Control output: • NPN open collector Max. 150 mA d.c. (resistance load) • Residual voltage: 1 V d.c. Below | • PNP open collector Max. 150 mA d.c. (resistance load) • Residual voltage: 1 V d.c. Below
• Response time: Max. 1 ms
• Degree of protection: IP64 (IEC 60529)
• Connection method: • Cable pull-out typed • Number of wires: 3P • Outer diameter: Ø3 ㎜ • Length: 2 m
• Light source (wavelength): Infrared LED (850 nm)

Technical Characteristics

The PLD series technical profile is centred on sensing method, detection range, target characteristics, output behaviour and response time. These parameters define the sensor's operating window and electrical interface. Response time: Max. 1 ms; • Control output: Red LED • Safety : green LED; Power voltage: 12 - 24 V d.c. ±10 %; Power consumption: Max. 30 ㎃ d.c..

Additional technical characteristics include Protection circuit: Reverse polarity protection, overcurrent protection; Ambient temperature & humidity: • When operating: -20 ~ 60 ℃, • when maintaining: -25 ~ 70 ℃, max. 35 ~ 85 % RH (without freezing); Degree of protection: IP64 (IEC 60529).

Design and Construction

The physical design of PLD series should be considered together with the installation environment and the available mounting or display arrangement. Material: • Case: PET • Lens cap: PC • Lens : PMMA; Cable: 3P (26 AWG), length : 2 m; Weight: 60g; • Number of wires: 3P.

Further construction and environmental details include Dielectric strength: 1000 V a.c. for 1 min; Vibration resistance: 10-55 ㎐ double amplitude 1.5mm, X,Y,Z each direction for 2 hours; Shock resistance: 500 m/s² X·Y·Z each direction for 3 times.

Integration and Operation

Integration of PLD series starts with matching its sensing method, supply voltage, output type and connection method to the control system. Sensing Type: Diffuse - reflective; Sensing distance: 2m; Power voltage: 12 - 24 V d.c. ±10 %; Control output: • NPN open collector Max. 150 mA d.c. (resistance load) • Residual voltage: 1 V d.c. Below | • PNP open collector Max. 150 mA d.c. (resistance load) • Residual voltage: 1 V d.c. Below.

Additional operating and interface details include Response time: Max. 1 ms; Degree of protection: IP64 (IEC 60529); Connection method: • Cable pull-out typed • Number of wires: 3P • Outer diameter: Ø3 ㎜ • Length: 2 m. These values provide a practical reference for wiring, setup and normal operation within the selected configuration.

Selection and Use

Choose PLD series by confirming the exact model or configuration against the required operating conditions. The available model information is PLD-R2N | PLD-R2P. Model: PLD-R2N | PLD-R2P; Sensing Type: Diffuse - reflective; Sensing distance: 2m; Power voltage: 12 - 24 V d.c. ±10 %.

Before installation, confirm Control output: • NPN open collector Max. 150 mA d.c. (resistance load) • Residual voltage: 1 V d.c. Below | • PNP open collector Max. 150 mA d.c. (resistance load) • Residual voltage: 1 V d.c. Below; Response time: Max. 1 ms; Degree of protection: IP64 (IEC 60529). Matching the model, electrical ratings, signal requirements, physical arrangement and environmental limits helps keep the product within its specified operating conditions.
