Product Overview

PAN series is a Hanyoung NUX area sensor for non-contact detection and machine sensing. The configuration is defined by its sensing method, sensing range, output arrangement and electrical requirements, with model information of NPN | PAN20-T□N | PAN40-T□N. Sensing distance: 7 m; Sensing object: Opaque object over Ø32 ㎜ | Opaque object over Ø52 ㎜; Control output: • NPN / PNP open collector output • Load Current: Max. 100mA (26.4VDC standard) • Residual voltage - NPN: Max. 1 V, PNP:Max. 1 V; Response Time: Max. 15 ㎳.

The sensing distance, target object, response time, output type and environmental limits are the key details to compare when selecting the sensor for a specific machine or detection point. Light source: IR (860nm); Operation mode: Transmitter - M/S MODE switch-return type (Master / Slave) Receiver - D/L MODE switch-return type (Dark ON / Light ON); Connection method: Relay connector type (Code length : 200 ㎜, Number of wires : 4P, Dimension : Ø5.5 ㎜); Material: Case | Aluminum.

Key Features

Key strengths of the PAN series come from the combination of its functional configuration and practical installation specifications. The following characteristics highlight the values that matter most when comparing the product with equipment requirements.

Sensing distance: 7 m; Control output: • NPN / PNP open collector output • Load Current: Max. 100mA (26.4VDC standard) • Residual voltage - NPN: Max. 1 V, PNP:Max. 1 V; Response Time: Max. 15 ㎳; Degree of protection: IP65 (IEC standard); Ambient temperature: During operation : -10 ~ +55 ℃, During storage : -25 ~ +70 ℃ (Without condensation or icing).

• Sensing distance: 7 m
• Control output: • NPN / PNP open collector output • Load Current: Max. 100mA (26.4VDC standard) • Residual voltage - NPN: Max. 1 V, PNP:Max. 1 V
• Response Time: Max. 15 ㎳
• Degree of protection: IP65 (IEC standard)
• Ambient temperature: During operation : -10 ~ +55 ℃, During storage : -25 ~ +70 ℃ (Without condensation or icing)
• Sensing object: Opaque object over Ø32 ㎜ | Opaque object over Ø52 ㎜
• Power voltage: 12 - 24 VDC ±10% Ripple(p-p)10% max
• Current consumption: Max. 170 ㎃ | Max. 100 ㎃
• Protection circuit: Power reverse connection protection, Output short-circuit over-current protection, Mutual interference prevation function
• Insulation resistance: Min. 20 ㏁ (500 VDC mega standard)

Technical Characteristics

The PAN series technical profile is centred on sensing method, detection range, target characteristics, output behaviour and response time. These parameters define the sensor's operating window and electrical interface. Power voltage: 12 - 24 VDC ±10% Ripple(p-p)10% max; Current consumption: Max. 170 ㎃ | Max. 100 ㎃; Protection circuit: Power reverse connection protection, Output short-circuit over-current protection, Mutual interference prevation function; Insulation resistance: Min. 20 ㏁ (500 VDC mega standard).

Additional technical characteristics include Noise immunity: Square wave noise by noise simulator (pulse width 1 ㎲) ±240 V; Dielectric strength: 1,000 VAC (50/60 Hz 1min); Vibration resistance: 10 - 55 ㎐, double amplitude: 1.5 ㎜, X·Y·Z in each direction for 2 hours.

Design and Construction

The physical design of PAN series should be considered together with the installation environment and the available mounting or display arrangement. lens: Acryl; Shock resistance: 500㎨ , X·Y·Z each direction 3 times; Ambient temperature: During operation : -10 ~ +55 ℃, During storage : -25 ~ +70 ℃ (Without condensation or icing); Ambient humidity: 35 ~ 85 % R.H. (Without condensation).

Further construction and environmental details include Degree of protection: IP65 (IEC standard).

Integration and Operation

Integration of PAN series starts with matching its sensing method, supply voltage, output type and connection method to the control system. Sensing distance: 7 m; Control output: • NPN / PNP open collector output • Load Current: Max. 100mA (26.4VDC standard) • Residual voltage - NPN: Max. 1 V, PNP:Max. 1 V; Response Time: Max. 15 ㎳; Degree of protection: IP65 (IEC standard).

Additional operating and interface details include Ambient temperature: During operation : -10 ~ +55 ℃, During storage : -25 ~ +70 ℃ (Without condensation or icing); Sensing object: Opaque object over Ø32 ㎜ | Opaque object over Ø52 ㎜; Power voltage: 12 - 24 VDC ±10% Ripple(p-p)10% max. These values provide a practical reference for wiring, setup and normal operation within the selected configuration.

Selection and Use

Choose PAN series by confirming the exact model or configuration against the required operating conditions. The available model information is NPN | PAN20-T□N | PAN40-T□N. Model: NPN | PAN20-T□N | PAN40-T□N; Sensing distance: 7 m; Control output: • NPN / PNP open collector output • Load Current: Max. 100mA (26.4VDC standard) • Residual voltage - NPN: Max. 1 V, PNP:Max. 1 V; Response Time: Max. 15 ㎳.

Before installation, confirm Degree of protection: IP65 (IEC standard); Ambient temperature: During operation : -10 ~ +55 ℃, During storage : -25 ~ +70 ℃ (Without condensation or icing); Sensing object: Opaque object over Ø32 ㎜ | Opaque object over Ø52 ㎜. Matching the model, electrical ratings, signal requirements, physical arrangement and environmental limits helps keep the product within its specified operating conditions.
