LP1 is a Hanyoung NUX panel meter designed for industrial measurement, indication and process monitoring. Its configuration is determined by the available input signals, measurement or recording functions, display and output characteristics, with model information of LP1. Input type: Non voltage input (INA) | Voltage input (INB) | Voltage input (INC); Input conditions: ▪ Remaining voltage when disconnected : Max. 0.5 V ▪ Max impedance when disconnected : Max. 10 kΩ ▪ Min impedance when connected : Min. 500 kΩ | * AC voltage input : 3-30 V AC * DC voltage input High: 4.5-30 V DC Low 0-2 V DC | ·AC voltage input : 30-240 V AC; HOLD Input type: Non voltage input; Measuring degree: ±0.1% rdg ±1 digit.
The listed measurement range, accuracy, input method, display format and connection details provide the main selection points for panel and control-system integration. Indication method: LCD Indication method, Zero blanking (letter height: 8.7mm); External setting switch: ▪ SW1-1 : rps / rpm, SW1-2 : ×1 / ×0.1 ▪ SW2-1 : RESET, SW2-2 : (rps, rpm) / Hz; External connection: terminal block (5 pin); Weight: approx 46 g (excluded the weight of box).
Key strengths of the LP1 come from the combination of its functional configuration and practical installation specifications. The following characteristics highlight the values that matter most when comparing the product with equipment requirements.
Measuring range: rpm | 1 ~ 10000 rpm; Indication method: LCD Indication method, Zero blanking (letter height: 8.7mm); Input type: Non voltage input (INA) | Voltage input (INB) | Voltage input (INC); Power supply: No power supply (built-in battery, exchangeable battery); External connection: terminal block (5 pin).
The main technical characteristics of LP1 are defined by its electrical ratings, operating inputs or outputs, performance values and control or indication functions. These specifications provide the working limits for the selected configuration. Measuring range: rpm | 1 ~ 10000 rpm; Power supply: No power supply (built-in battery, exchangeable battery); Indication method: LCD Indication method, Zero blanking (letter height: 8.7mm); Input type: Non voltage input (INA) | Voltage input (INB) | Voltage input (INC).
Additional technical characteristics include External connection: terminal block (5 pin); Ambient temperature: -10 ~ 55 ℃ (no dew condensation, no icing); Input conditions: ▪ Remaining voltage when disconnected : Max. 0.5 V ▪ Max impedance when disconnected : Max. 10 kΩ ▪ Min impedance when connected : Min. 500 kΩ | * AC voltage input : 3-30 V AC * DC voltage input High: 4.5-30 V DC Low 0-2 V DC | ·AC voltage input : 30-240 V AC.
The physical design of LP1 should be considered together with the installation environment and the available mounting or display arrangement. Insulation resistance: Min. 100 MΩ (500 V d.c mega standard, between the electric conduction terminal and exposed non-charging metal part); Dielectric strength: 2000 V a.c (50 / 60 ㎐ for 1 min, between the electric conduction terminal and exposed non-charging metal part); Vibration: Durability | 10-55 Hz (1 minute cycle) double amplitude, each direction of X, Y, Z for 1 hour; Shock: Durability | 300 m/s² each direction of x, y, z 3 times.
Further construction and environmental details include Ambient temperature: -10 ~ 55 ℃ (no dew condensation, no icing); Storage temperature: -20 ~ 65 ℃ (no dew condensation, no icing); Ambient humidity: 35 ~ 85 % R.H..
Integration of LP1 begins with matching its connection, input or control signal and output requirements to the surrounding equipment. Measuring range: rpm | 1 ~ 10000 rpm; Indication method: LCD Indication method, Zero blanking (letter height: 8.7mm); Input type: Non voltage input (INA) | Voltage input (INB) | Voltage input (INC); Power supply: No power supply (built-in battery, exchangeable battery).
Additional operating and interface details include External connection: terminal block (5 pin); Ambient temperature: -10 ~ 55 ℃ (no dew condensation, no icing); Input conditions: ▪ Remaining voltage when disconnected : Max. 0.5 V ▪ Max impedance when disconnected : Max. 10 kΩ ▪ Min impedance when connected : Min. 500 kΩ | * AC voltage input : 3-30 V AC * DC voltage input High: 4.5-30 V DC Low 0-2 V DC | ·AC voltage input : 30-240 V AC. These values provide a practical reference for wiring, setup and normal operation within the selected configuration.
Choose LP1 by confirming the exact model or configuration against the required operating conditions. The available model information is LP1. Model: LP1; Measuring range: rpm | 1 ~ 10000 rpm; Indication method: LCD Indication method, Zero blanking (letter height: 8.7mm); Input type: Non voltage input (INA) | Voltage input (INB) | Voltage input (INC).
Before installation, confirm Power supply: No power supply (built-in battery, exchangeable battery); External connection: terminal block (5 pin); Ambient temperature: -10 ~ 55 ℃ (no dew condensation, no icing). Matching the model, electrical ratings, signal requirements, physical arrangement and environmental limits helps keep the product within its specified operating conditions.
| Specification | Details |
|---|---|
| Model | LP1 |
| Power supply | No power supply (built-in battery, exchangeable battery) |
| Indication method | LCD Indication method, Zero blanking (letter height: 8.7mm) |
| Battery life | Approximately more than 3 years (about 25 ℃) |
| Input type | Non voltage input (INA) | Voltage input (INB) | Voltage input (INC) |
| Input conditions | ▪ Remaining voltage when disconnected : Max. 0.5 V ▪ Max impedance when disconnected : Max. 10 kΩ ▪ Min impedance when connected : Min. 500 kΩ | * AC voltage input : 3-30 V AC * DC voltage input High: 4.5-30 V DC Low 0-2 V DC | ·AC voltage input : 30-240 V AC |
| HOLD Input type | Non voltage input |
| Measuring degree | ±0.1% rdg ±1 digit |
| Measuring range | rpm | 1 ~ 10000 rpm |
| 0.1 rpm | 0.1 ~ 1000.0 rpm |
| rps | 1 ~ 1000 rps |
| Hz | 1 ~ 1000 Hz |
| 0.1 Hz | 0.1 ~ 100.0 Hz |
| External setting switch | ▪ SW1-1 : rps / rpm, SW1-2 : ×1 / ×0.1 ▪ SW2-1 : RESET, SW2-2 : (rps, rpm) / Hz |
| External connection | terminal block (5 pin) |
| Insulation resistance | Min. 100 MΩ (500 V d.c mega standard, between the electric conduction terminal and exposed non-charging metal part) |
| Dielectric strength | 2000 V a.c (50 / 60 ㎐ for 1 min, between the electric conduction terminal and exposed non-charging metal part) |
| Vibration | Durability | 10-55 Hz (1 minute cycle) double amplitude, each direction of X, Y, Z for 1 hour |
| Mal function | 10 - 55 ㎐ double amplitude, each direction of x, y, z for 10 min |
| Shock | Durability | 300 m/s² each direction of x, y, z 3 times |
| Mal function | 100 m/s² each direction of x, y, z 3 times |
| Ambient temperature | -10 ~ 55 ℃ (no dew condensation, no icing) |
| Storage temperature | -20 ~ 65 ℃ (no dew condensation, no icing) |
| Ambient humidity | 35 ~ 85 % R.H. |
| Weight | approx 46 g (excluded the weight of box) |
| No | Type | Category | Title | File |
| 1 | Manual > Instruction Manual | Panel Meter | LP1 Instruction Manual |
| 1 | CAD > 3D | Panel Meter | LP1 (3D) |
| ▪ Remaining voltage when disconnected | Max. 0.5 V |
| * AC voltage input | 3-30 V AC |
| ·AC voltage input | 30-240 V AC |
