Product Overview

HPAN series is a Hanyoung NUX sensor controller for processing sensor signals and providing control outputs. Its model configuration includes HPAN-C7 | HPAN-CT7 | HPAN-C7W. Control output: Contact | OUT | OUT1, OUT2; Output response speed: Relay contact : approximately 10 ms; Power supply voltage: 100 V - 240 V a.c. (50 Hz / 60 Hz) ± 10 %; Power consumption: Approx 5 VA.

Input levels, sensor supply, output type, response speed and operating functions determine how the controller fits into the control circuit. Operation mode: IN,ES AND function | IN,ES AND function operation/ AND trigger function operation | -; Timer function: - | 3 types of timer set up mode (ON DELAY,OFF DELAY, ONE SHORT DELAY) time set up function (min-max) | -; Weight: approximately 160 g; Noise immunity: Square wave noise due to noise simulator (1 us pulse per 16 ns) ±2 kV (Apply to power input terminal).

Key Features

Key strengths of the HPAN series come from the combination of its functional configuration and practical installation specifications. The following characteristics highlight the values that matter most when comparing the product with equipment requirements.

Power supply voltage: 100 V - 240 V a.c. (50 Hz / 60 Hz) ± 10 %; Power for sensor: 12 V d.c. ( ±10 %), 200 mA Max; Input: [H] level 4 - 30 V d.c., [L] level 0 - 2 V d.c. Pull up / Pull down resistance connection (4.7 kΩ) by NPN / PNP switch setting Inversion function of NORM INV input signal; Control output: Contact | OUT | OUT1, OUT2; Output response speed: Relay contact : approximately 10 ms.

• Power supply voltage: 100 V - 240 V a.c. (50 Hz / 60 Hz) ± 10 %
• Power for sensor: 12 V d.c. ( ±10 %), 200 mA Max
• Input: [H] level 4 - 30 V d.c., [L] level 0 - 2 V d.c. Pull up / Pull down resistance connection (4.7 kΩ) by NPN / PNP switch setting Inversion function of NORM INV input signal
• Control output: Contact | OUT | OUT1, OUT2
• Output response speed: Relay contact : approximately 10 ms
• Operation mode: IN,ES AND function | IN,ES AND function operation/ AND trigger function operation | -
• Timer function: - | 3 types of timer set up mode (ON DELAY,OFF DELAY, ONE SHORT DELAY) time set up function (min-max) | -
• Noise immunity: Square wave noise due to noise simulator (1 us pulse per 16 ns) ±2 kV (Apply to power input terminal)

Technical Characteristics

The main technical characteristics of HPAN series are defined by its electrical ratings, operating inputs or outputs, performance values and control or indication functions. These specifications provide the working limits for the selected configuration. Dielectric strength: 1 minute within 1500 V a.c., 60 Hz; Insulation resistance: 10 MΩ (500 V d.c. mega between the power and the output); Vibration resistance: 10 - 55 Hz double amplituded 0.75 ㎜, X · Y · Z 2 hour for each direction (when power turned OFF); Shock resistance: 100 m/s² (approximately 10G), X · Y · Z 2 hour for each direction (when power turned OFF).

Additional technical characteristics include .

Design and Construction

The physical design of HPAN series should be considered together with the installation environment and the available mounting or display arrangement. Power supply voltage: 100 V - 240 V a.c. (50 Hz / 60 Hz) ± 10 %; Power for sensor: 12 V d.c. ( ±10 %), 200 mA Max; Input: [H] level 4 - 30 V d.c., [L] level 0 - 2 V d.c. Pull up / Pull down resistance connection (4.7 kΩ) by NPN / PNP switch setting Inversion function of NORM INV input signal; Control output: Contact | OUT | OUT1, OUT2.

Further construction and environmental details include Output response speed: Relay contact : approximately 10 ms; Operation mode: IN,ES AND function | IN,ES AND function operation/ AND trigger function operation | -; Timer function: - | 3 types of timer set up mode (ON DELAY,OFF DELAY, ONE SHORT DELAY) time set up function (min-max) | -.

Integration and Operation

Integration of HPAN series begins with matching its connection, input or control signal and output requirements to the surrounding equipment. Power supply voltage: 100 V - 240 V a.c. (50 Hz / 60 Hz) ± 10 %; Power for sensor: 12 V d.c. ( ±10 %), 200 mA Max; Input: [H] level 4 - 30 V d.c., [L] level 0 - 2 V d.c. Pull up / Pull down resistance connection (4.7 kΩ) by NPN / PNP switch setting Inversion function of NORM INV input signal; Control output: Contact | OUT | OUT1, OUT2.

Additional operating and interface details include Output response speed: Relay contact : approximately 10 ms; Operation mode: IN,ES AND function | IN,ES AND function operation/ AND trigger function operation | -; Timer function: - | 3 types of timer set up mode (ON DELAY,OFF DELAY, ONE SHORT DELAY) time set up function (min-max) | -. These values provide a practical reference for wiring, setup and normal operation within the selected configuration.

Selection and Use

Choose HPAN series by confirming the exact model or configuration against the required operating conditions. The available model information is HPAN-C7 | HPAN-CT7 | HPAN-C7W. Model: HPAN-C7 | HPAN-CT7 | HPAN-C7W; Function: Common | High function (timer) | Connecting 2 internal sensors; Power supply voltage: 100 V - 240 V a.c. (50 Hz / 60 Hz) ± 10 %; Power for sensor: 12 V d.c. ( ±10 %), 200 mA Max.

Before installation, confirm Input: [H] level 4 - 30 V d.c., [L] level 0 - 2 V d.c. Pull up / Pull down resistance connection (4.7 kΩ) by NPN / PNP switch setting Inversion function of NORM INV input signal; Control output: Contact | OUT | OUT1, OUT2; Output response speed: Relay contact : approximately 10 ms. Matching the model, electrical ratings, signal requirements, physical arrangement and environmental limits helps keep the product within its specified operating conditions.
