The DELTA DTA4848R0 T/C is a high-performance power supply inverter designed for industrial applications. This VFD power supply operates across 36-75V DC input with precise output voltage control, delivering stable performance in demanding environments. Key features include a 120Hz ripple rejection capability, 0.990-1.010V DC output range, and robust thermal operation from -40°C to 85°C ambient temperatures.
The DELTA DTA4848R0 T/C is a precision power supply inverter engineered for industrial power conversion applications requiring reliable DC voltage regulation across wide input ranges. This VFD power supply delivers exceptional stability and efficiency for critical systems where precise voltage control and minimal ripple are essential. With a robust operating temperature range of -40°C to 85°C and precise output voltage regulation from 0.990V to 1.010V at full load, the DTA4848R0 T/C ensures consistent performance in harsh industrial environments while maintaining compatibility with a broad range of DC input voltages from 36V to 75V.
The DTA4848R0 T/C maintains exceptional output voltage stability across varying loads and temperatures. At full load (Io.max) and 25°C ambient temperature, the output voltage ranges from 0.990V to 1.010V DC, ensuring precise regulation within a 0.1% tolerance. This tight control is critical for sensitive electronic systems requiring stable power supplies, particularly in applications where voltage fluctuations could disrupt operation.
This power supply exhibits rapid transient response capabilities, with a positive step change in output current from 50% to 75% of maximum current generating only 350-500 mV voltage change. Similarly, negative step changes produce minimal voltage fluctuations (-500 to -350 mV). The 0.1A/µs current slew rate ensures smooth transitions during load changes, making it suitable for applications with dynamic power demands.
The DTA4848R0 T/C features optimized input power consumption across different operating conditions. At 48V input, the no-load current is 80-110-140 mA, while the off-converter input current is as low as 10-18-26 mA. These low power consumption characteristics minimize energy waste during idle periods and ensure efficient operation in power-sensitive industrial systems.
Engineered for extreme environmental conditions, the DTA4848R0 T/C operates reliably in ambient temperatures ranging from -40°C to 85°C. This wide temperature range ensures consistent performance in both cold and hot industrial environments, such as outdoor installations or high-temperature manufacturing facilities. The storage temperature range extends to -55°C to 125°C, supporting deployment in extreme conditions.
The DELTADTA4848R0 T/C is an industrial Power Supply. Selection should be based on the documented characteristics and the requirements of the intended application.
| Feature | Specification |
|---|---|
| Operating Input Voltage | 36 48 75 Vdc |
| Maximum Input Current | Vin=36V, 100% Load 19 A |
| No-Load Input Current | Vin=48V 80 110 140 mA |
| Off Converter Input Current | Vin=48V 10 18 26 mA |
| Input Voltage Ripple Rejection | 120 Hz 50 dB |
| Output Voltage Set Point | Vin=48V, Io=Io.max, Tc=25°C 0.990 1.000 1.010 Vdc |
| Output Voltage Current Transient | Vin=48V, Load Slew rate 0.1A/µs with a 1uF ceramic |
| Operating ambient Temperature | -40 85 °C |
| Storage Temperature | -55 125 °C |
| Output Voltage Trim and PMBUS Range | Vin=36V to 75V, Pout ≦ max rated power,Io ≦ Io.max -33.3 +10 % |
| Output Voltage Remote Sense Range (note 2) | Vin=36V to 75V, Pout ≦ max rated power,Io ≦ Io.max -5.8 +10 % |
| Output Voltage Ripple and Noise | Vin=48V, Full load, 20MHz bandwidth |
| Positive Step Change in Output Current | 50% Io.max to 75% Io.max 350 500 mV |
| Negative Step Change in Output Current | 75% Io.max to 50% Io.max -500 -350 mV |
| Output voltage Rise Time | From 10%Vo final value to 90%Vo final value 30 ms |
