IFM DI6005 is a compact evaluation unit designed for industrial speed monitoring. It provides integrated sensing and evaluation for rotating equipment. The device is suitable for monitoring speed conditions in motors, conveyors and machine drives. Its compact design allows direct installation near the monitored machine component. IO-Link functionality supports modern automation integration.
Explore performance details, construction highlights, applications, and technical information in one clear overview.
The DI6005 is designed to provide reliable speed information for machine-control applications. It can detect abnormal speed conditions and support machine protection. Its compact construction helps simplify installation. The device can be connected to control systems for further processing. It is suitable for continuous industrial monitoring.
The unit uses inductive speed sensing and can monitor rotational movement. IFM's IO-Link documentation identifies DI6005 as a speed monitor with a 0–32000 rpm process range. It supports COM2 communication and has a minimum cycle time of 3.7 ms in the referenced IODD.
IO-Link enables device identification, parameterisation and diagnostic functionality. This can reduce commissioning time and make maintenance easier. Process information can be transferred to an automation controller. The device can therefore form part of a connected industrial monitoring architecture. It is suitable for applications where speed information needs to be available digitally.
Compact speed monitor
Inductive speed detection
IO-Link communication
0–32000 rpm process range
Digital process data
Device identification
Diagnostic functions
Parameterisation
Industrial housing
Machine monitoring
PLC integration
Compact installation
Motor speed monitoring
Conveyor drives
Rotating machinery
Machine tools
Production equipment
Material handling
Drive systems
Condition monitoring
Industrial automation
Preventive maintenance
| Parameter | Details |
|---|---|
| Model | DI6005 |
| Product type | Compact speed monitor |
| Measuring principle | Inductive |
| Application | Speed monitoring |
| Process range | 0–32000 rpm |
| IO-Link | Yes |
| Transmission | COM2 |
| Minimum cycle time | 3.7 ms |
| SIO mode | Supported |
| Data storage | Supported |
| Device identification | Supported |
| Diagnosis | Supported |
| Process data | Supported |
| Supply voltage | Refer to datasheet |
| Current consumption | Refer to datasheet |
| Sensing range | Refer to datasheet |
| Output | Refer to datasheet |
| Housing | Refer to datasheet |
| Connection | Refer to datasheet |
| Protection rating | Refer to datasheet |
| Operating temperature | Refer to datasheet |
| Mounting | Industrial |
| Target | Metallic |
| Product family | Speed sensors |
| Manufacturer | IFM |
