The Vision Processors Accessories - 933-56-027 is a industrial product from Datasensing. The documented values above identify the exact configuration and are the basis for technical selection and system integration.
The Datasensing Vision Processors Accessories 933-56-027 is a multi-camera vision processor designed for industrial applications. It features 2x, 4x, or 8x PoE camera ports supporting 1000 Mbps Base-T (up to 7W per channel) and 2x 10/100/1000 Mbps LAN ports for network connectivity.
Operates within a temperature range of 0 to +50 °C (+32 to +122 °F) and features IP20 mechanical protection. The unit measures 145 mm (H) x 192 mm (W) x 230 mm (D) and runs on Windows 10 IoT Enterprise.
The documented configuration includes (1920 x 1200 resolution) - VGA, DVI: Camera Interface.
The documented configuration includes Camera Interface: 2x, 4x or 8x - 1000 Mbps Base-T, PoE camera ports (Up to 7W per channel); Network Interface: 2x LAN ports - 10/100/1000 Mbps Base-T; Serial Communications: 2x RS-232 serial port; Power Requirements: 24 VDC +/- 25% (5.5 A @ 24 VDC); 8x USB 3.0 ports: Supports EtherNet/IP, Profinet, Modbus TCP and OPC.
The documented configuration includes Dimensions: 145 (H) x 192 (W) x 230 (D) mm 5.7 (H) x 7.56 (W) x 9.05 (D) in.; Operating Temperature: 0 to +50 °C / +32 to +122 °F; Mechanical Protection: IP20; Dimensions: 145 (H) x 192 (W) x 230 (D) mm; Humidity: 5 to 95% (non-condensing).
The documented configuration includes Operating System: Windows 10 IoT Enterprise; Certifications (Safety Compliance): CE/FCC, c-UL-us, KCC.
The documented configuration includes Comm Connectivity: Supports EtherNet/IP, Profinet, Modbus TCP and OPC; I/O: 16 in-16 out - single I/O; card configurable PNP/NPN.
| Feature | Specification |
|---|---|
| Camera Interface | 2x, 4x or 8x - 1000 Mbps Base-T, PoE camera ports (Up to 7W per channel) |
| Network Interface | 2x LAN ports - 10/100/1000 Mbps Base-T |
| Dimensions | 145 (H) x 192 (W) x 230 (D) mm 5.7 (H) x 7.56 (W) x 9.05 (D) in. |
| Operating Temperature | 0 to +50 °C / +32 to +122 °F |
| Mechanical Protection | IP20 |
| Dimensions | 145 (H) x 192 (W) x 230 (D) mm |
| Serial Communications | 2x RS-232 serial port |
| Comm Connectivity | Supports EtherNet/IP, Profinet, Modbus TCP and OPC |
| I/O | 16 in-16 out - single I/O; card configurable PNP/NPN |
| Operating System | Windows 10 IoT Enterprise |
| Power Requirements | 24 VDC +/- 25% (5.5 A @ 24 VDC) |
| Humidity | 5 to 95% (non-condensing) |
| 8x USB 3.0 ports | Supports EtherNet/IP, Profinet, Modbus TCP and OPC |
| Certifications (Safety Compliance) | CE/FCC, c-UL-us, KCC |
| (1920 x 1200 resolution) - VGA, DVI | Camera Interface |
