The Vision Processors Accessories -933-54-357 is a industrial product from Datasensing. The documented values above identify the exact configuration and are the basis for technical selection and system integration.
The Datasensing Vision Processors Accessories -933-54-357 is a multi-camera vision processor designed for industrial automation environments. It features 2x or 4x 1000 Mbps Base-T, PoE camera ports (up to 7 W per channel) and 2x 10/100/1000 Mbps Base-T LAN ports for reliable network connectivity.
Operating within a temperature range of 0 to +50 °C (+32 to +122 °F), this unit offers IP20 mechanical protection and dimensions of 270 (H) x 130 (W) x 255 (D) mm (10.6 x 5.1 x 10 in). The device runs on Windows 10 IoT Enterprise for stable industrial operations.
The documented configuration includes Intel® HD Graphics 510 (1920x1200 resolution) - DisplayPort, DVI: Camera Interface; 16 in -16 out, PNP card or NPN card, 200μs response time: Operating System.
The documented configuration includes Camera Interface: 2x o 4x 1000 Mbps Base-T, PoE camera ports (Up to 7 W per channell); Network Interface: 2x LAN ports - 10/100/1000 Mbps Base-T; Serial Communications: 1x RS-232 serial port; Power Requirements: 24 VDC +/- 25% (5.5 A @ 24 VDC); 4x USB3.0 ports: Supports EtherNet/IP, Profinet, Modbus TCP and OPC.
The documented configuration includes Dimensions: 270 (H) x 130 (W) x 255 (D) mm 10.6 (H) x 5.1 (W) x 10 (D) in.; Operating Temperature: 0 to +50 °C / +32 to +122 °F; Mechanical Protection: IP20; Dimensions: 270 (H) x 130 (W) x 255 (D) mm; Humidity: 5 to 95% (non-condensing).
The documented configuration includes Operating System: Windows 10 IoT Enterprise; Certifications (Safety Compliance): CE/FCC, c-UL-us, KCC.
The documented configuration includes Comm Connectivity: Supports EtherNet/IP, Profinet, Modbus TCP and OPC; I/O: 16 in -16 out, PNP card or NPN card, 200μs response time.
| Feature | Specification |
|---|---|
| Camera Interface | 2x o 4x 1000 Mbps Base-T, PoE camera ports (Up to 7 W per channell) |
| Network Interface | 2x LAN ports - 10/100/1000 Mbps Base-T |
| Dimensions | 270 (H) x 130 (W) x 255 (D) mm 10.6 (H) x 5.1 (W) x 10 (D) in. |
| Operating Temperature | 0 to +50 °C / +32 to +122 °F |
| Mechanical Protection | IP20 |
| Dimensions | 270 (H) x 130 (W) x 255 (D) mm |
| Serial Communications | 1x RS-232 serial port |
| Comm Connectivity | Supports EtherNet/IP, Profinet, Modbus TCP and OPC |
| I/O | 16 in -16 out, PNP card or NPN card, 200μs response time |
| Operating System | Windows 10 IoT Enterprise |
| Power Requirements | 24 VDC +/- 25% (5.5 A @ 24 VDC) |
| Humidity | 5 to 95% (non-condensing) |
| 4x USB3.0 ports | Supports EtherNet/IP, Profinet, Modbus TCP and OPC |
| Certifications (Safety Compliance) | CE/FCC, c-UL-us, KCC |
| Intel® HD Graphics 510 (1920x1200 resolution) - DisplayPort, DVI | Camera Interface |
| 16 in -16 out, PNP card or NPN card, 200μs response time | Operating System |
