Product Summary

The Vision Processors Accessories - 601-0008 is a industrial product from Datasensing. The documented values above identify the exact configuration and are the basis for technical selection and system integration.

Datasensing Vision Processors Accessories - 601-0008

The Datasensing Vision Processors Accessories - 601-0008 is a multi-camera vision processor designed for industrial automation applications. It features 2x or 4x 1000 Mbps Base-T, PoE camera ports (up to 7 W per channel) and 2x 10/100/1000 Mbps Base-T LAN ports for reliable network connectivity.

Key Specifications

• Camera Interface: 2x or 4x 1000 Mbps Base-T, PoE camera ports (up to 7 W per channel)
• Network Interface: 2x LAN ports - 10/100/1000 Mbps Base-T
• Operating Temperature: 0 to +50 °C / +32 to +122 °F
• Mechanical Protection: IP20
• Serial Communications: 1x RS-232 serial port
• Comm Connectivity: Supports EtherNet/IP, Profinet, Modbus TCP, and OPC
• I/O: 16 in -16 out, PNP or NPN card, 200μs response time
• Operating System: Windows 10 IoT Enterprise

Physical and Environmental Specifications

Dimensions: 270 (H) x 130 (W) x 255 (D) mm (10.6 x 5.1 x 10 in). The device operates within an environmental range of 0 to +50 °C and features IP20 mechanical protection for industrial settings.

Performance

The documented configuration includes Intel® HD Graphics 510 (1920x1200 resolution) - DisplayPort, DVI: Camera Interface; 16 in -16 out, PNP card or NPN card, 200μs response time: Operating System.

Electrical and Interface

The documented configuration includes Camera Interface: 2x o 4x 1000 Mbps Base-T, PoE camera ports (Up to 7 W per channell); Network Interface: 2x LAN ports - 10/100/1000 Mbps Base-T; Serial Communications: 1x RS-232 serial port; Power Requirements: 24 VDC +/- 25% (5.5 A @ 24 VDC); 4x USB3.0 ports: Supports EtherNet/IP, Profinet, Modbus TCP and OPC.

Mechanical and Environmental

The documented configuration includes Dimensions: 270 (H) x 130 (W) x 255 (D) mm 10.6 (H) x 5.1 (W) x 10 (D) in.; Operating Temperature: 0 to +50 °C / +32 to +122 °F; Mechanical Protection: IP20; Dimensions: 270 (H) x 130 (W) x 255 (D) mm; Humidity: 5 to 95% (non-condensing).

Configuration and Functional

The documented configuration includes Operating System: Windows 10 IoT Enterprise; Certifications (Safety Compliance): CE/FCC, c-UL-us, KCC.

General

The documented configuration includes Comm Connectivity: Supports EtherNet/IP, Profinet, Modbus TCP and OPC; I/O: 16 in -16 out, PNP card or NPN card, 200μs response time.
