The DELTA VFD007EL23A is a servo motor inverter designed for precise motion control applications. This model supports both single-phase (200-240V, 50/60Hz) and three-phase (380-480V, 50/60Hz) power inputs with a rated output capacity of up to 4.0 kVA. It offers versatile cooling options and is suitable for industrial machinery requiring high precision and reliability.
The DELTA VFD007EL23A is a high-performance servo motor inverter engineered for demanding industrial applications where precise motion control and energy efficiency are critical. This model delivers robust performance across a wide voltage range (230V to 460V) and supports both single-phase and three-phase power inputs, making it ideal for machinery requiring smooth, accurate motion control. Its compact design and efficient thermal management ensure reliable operation in diverse industrial environments while maintaining compliance with stringent technical specifications.
The DELTA VFD007EL23A features precise technical specifications tailored for industrial use. Key parameters include: Voltage range (230V to 460V), rated input current (4.9A to 10.0A), output capacity (0.6 kVA to 7.4 kVA), and maximum applicable motor output (0.2 kW to 4.0 kW). The model supports both single-phase and three-phase power inputs with a tolerance of ±10% for voltage and ±5% for frequency, ensuring reliable operation across diverse industrial environments.
Designed for energy-efficient operation, the VFD007EL23A delivers optimal performance across a wide range of industrial applications. It operates with a rated output capacity of up to 4.0 kVA, supporting motors up to 2.2 kW (3.0 HP). The model features dual cooling options: natural cooling for lower power ranges (0.2-0.75 kW) and fan cooling for higher power (1.5 kW), ensuring thermal stability without compromising efficiency.
The VFD007EL23A maintains stable performance within tight voltage and frequency tolerances. It accepts a voltage range of ±10% (180V-264V for 230V; 342V-528V for 460V) and a frequency range of ±5% (47Hz-63Hz), making it suitable for environments with fluctuating power conditions. This robust tolerance ensures consistent operation without requiring frequent adjustments.
The DELTAVFD007EL23A is an industrial Servo Motor. Selection should be based on the documented characteristics and the requirements of the intended application.
| Feature | Specification |
|---|---|
| Voltage | 230 V 460 V |
| Rated Voltage / Frequency | Single Phase, AC 200 V ~ 240 V，50 / 60 Hz Three Phase, AC 380 V ~ 480 V，50 / 60 H |
| Input Rating | Rated Input Current (A) 4.9 6.5 9.3 15.7 24.0 1.8 3.2 4.3 7.1 10.0 |
| Voltage Tolerance | ±10 % (180 V ~ 264 V) ±10 % (342 V ~ 528 V) |
| Frequency Tolerance | ±5 % (47 Hz ~ 63 Hz) |
| Frame A1 | Natural Cooling -10°C ~ 50°C 230 V: 0.2 ~ 0.75 kW 460 V: 0.4 ~ 0.75 kW |
| Frame A2 | Fan Cooling 460 V: 1.5 kW |
| Frame B | 230 V: 1.5 ~ 2.2 kW 460 V: 2.2 ~ 4.0 kW |
| Max. Applicable Motor Output (kW) | 0.2 0.4 0.75 1.5 2.2 0.4 0.75 1.5 2.2 4.0 |
| Max. Applicable Motor Output (HP) | 0.25 0.5 1.0 2.0 3.0 0.5 1.0 2.0 3.0 5.5 |
| Output Rating | Rated Output Capacity (kVA) 0.6 1.0 1.6 2.9 4.2 1.2 2.0 3.3 4.4 7.4 |
