Explore performance details, construction highlights, applications, and technical information in one clear overview.
Findeva T-65/HP is a pneumatic turbine vibrator designed to generate strong vibration at large amplitude. The T-series uses a high-eccentric-torque rotor and continuously variable speed to match vibration output to the material and process.
The T-65/HP generates vibration from the rotor's imbalance and high eccentric working torque. The T-series is designed for strong vibration at relatively high working torque and provides continuously variable operation.
At 2, 4 and 6 bar, the model operates at 8.5, 10.5 and 12.0 ×10³ min⁻¹, with centrifugal force of 1300, 2050 and 2600 N.
The model uses an anodized extruded aluminium alloy housing, synthetic caps and a rotor supported by paired ball bearings. Published weight is 0.97 kg.
| Brand | Findeva |
|---|---|
| Product family | T Turbine Vibrator |
| Model | T-65/HP |
| Rated frequency @ 2 / 4 / 6 bar | 8.5 / 10.5 / 12.0 ×10³ min⁻¹ |
| Centrifugal force @ 2 / 4 / 6 bar | 1300 / 2050 / 2600 N |
| Air consumption @ 2 / 4 / 6 bar | 108 / 193 / 290 l/min |
| Dimensions A / Width / C / D / E / F | 65 / 64 / 113 / 90 / 16 / 9 mm |
| Air connections | G 1/4" / G 1/4" |
| Weight | 0.97 kg |
| Maximum operating temperature | 100°C |
Emptying bunkers, screen filters, vibrating tables, preventing adhesion in pipelines and silos, transporting fine powders and moving bulk materials.
The T-65/HP is designed for compressed-air operation within the published Findeva operating range. Its model-specific construction and pneumatic characteristics provide controlled vibration or impact for material-flow and process equipment.
| Brand | Findeva |
|---|---|
| Product family | T Turbine Vibrator |
| Model | T-65/HP |
| Rated frequency @ 2 / 4 / 6 bar | 8.5 / 10.5 / 12.0 ×10³ min⁻¹ |
| Centrifugal force @ 2 / 4 / 6 bar | 1300 / 2050 / 2600 N |
| Air consumption @ 2 / 4 / 6 bar | 108 / 193 / 290 l/min |
| Dimensions A / Width / C / D / E / F | 65 / 64 / 113 / 90 / 16 / 9 mm |
| Air connections | G 1/4" / G 1/4" |
| Weight | 0.97 kg |
| Maximum operating temperature | 100°C |
