SSR-2C is a Hanyoung NUX solid state relay for electronic switching of electrical loads. The available configurations are identified by the model options, load voltage and rated load current, with model information of SSR- 2C252Z | SSR- 2C402Z | SSR- 2C254Z | SSR- 2C404Z. Frequency: 50/60 Hz (dual usage); Rated load current: 25 A | 40 A | 25 A | 40 A; Leakage current: Max. 10 mA; Output ON voltage drop: Max. 1.8 V (RMS).
Control-signal requirements, load range, leakage current, surge capability and thermal conditions are important when selecting the relay for a switching circuit. Weight: Approx. 670 | Approx. 900 | Approx. 670 | Approx. 900; Insulation resistance: 500 V d.c. 100 MΩ (input/output and among cases); Dielectric strength: 2,500 V a.c. (60 ㎐ for one minute); Vibration resistance: 10 -55 Hz, double amplitude: 1.5 mm, each X· Y· Z axis for 2 hours.
Key strengths of the SSR-2C come from the combination of its functional configuration and practical installation specifications. The following characteristics highlight the values that matter most when comparing the product with equipment requirements.
Rated load current: 25 A | 40 A | 25 A | 40 A; Peak voltage (non-repetition): 1,200 V; Leakage current: Max. 10 mA; Frequency: 50/60 Hz (dual usage); Output ON voltage drop: Max. 1.8 V (RMS).
The SSR-2C electrical performance is defined by its control signal, load voltage, rated current, switching limits and protection characteristics. These values establish the operating range for the solid state switching circuit. Response speed: Max. 1/2 Cycle + 1 ms; Shock resistance: 1,000 m/s² each X· Y· Z axis for 3 times; Storage temperature: -30 ~ 90 ℃; Ambient temperature: -20 ~ 80 ℃ (without condensation).
Additional technical characteristics include Ambient humidity: 45 ~ 85 % R.H..
The physical design of SSR-2C should be considered together with the installation environment and the available mounting or display arrangement. Rated load current: 25 A | 40 A | 25 A | 40 A; Peak voltage (non-repetition): 1,200 V; Leakage current: Max. 10 mA; Frequency: 50/60 Hz (dual usage).
Further construction and environmental details include Output ON voltage drop: Max. 1.8 V (RMS); Response speed: Max. 1/2 Cycle + 1 ms; Insulation resistance: 500 V d.c. 100 MΩ (input/output and among cases).
Integration of SSR-2C depends on matching the control signal and load circuit to the relay's rated voltage and current characteristics. Rated load current: 25 A | 40 A | 25 A | 40 A; Peak voltage (non-repetition): 1,200 V; Leakage current: Max. 10 mA; Frequency: 50/60 Hz (dual usage).
Additional operating and interface details include Output ON voltage drop: Max. 1.8 V (RMS); Response speed: Max. 1/2 Cycle + 1 ms; Insulation resistance: 500 V d.c. 100 MΩ (input/output and among cases). These values provide a practical reference for wiring, setup and normal operation within the selected configuration.
Choose SSR-2C by confirming the exact model or configuration against the required operating conditions. The available model information is SSR- 2C252Z | SSR- 2C402Z | SSR- 2C254Z | SSR- 2C404Z. Model: SSR- 2C252Z | SSR- 2C402Z | SSR- 2C254Z | SSR- 2C404Z; Rated load current: 25 A | 40 A | 25 A | 40 A; Peak voltage (non-repetition): 1,200 V; Leakage current: Max. 10 mA.
Before installation, confirm Frequency: 50/60 Hz (dual usage); Output ON voltage drop: Max. 1.8 V (RMS); Response speed: Max. 1/2 Cycle + 1 ms. Matching the model, electrical ratings, signal requirements, physical arrangement and environmental limits helps keep the product within its specified operating conditions.
| Specification | Details |
|---|---|
| Model | SSR- 2C252Z | SSR- 2C402Z | SSR- 2C254Z | SSR- 2C404Z |
| Load | Operating load voltage | 90 - 240 V a.c. | 90 - 480 V a.c. |
| Peak voltage (non-repetition) | 1,200 V |
| Rated load current | 25 A | 40 A | 25 A | 40 A |
| Frequency | 50/60 Hz (dual usage) |
| Surge current (8.3 ms non- repetition) | 420 A |
| Leakage current | Max. 10 mA |
| Output ON voltage drop | Max. 1.8 V (RMS) |
| Input | Operating voltage range | 4 - 32 V d.c. |
| Impedance | Max. 4 KΩ |
| Operating voltage | Min. 3 V d.c. |
| Reset voltage | Max. 1.5 V d.c. |
| Response speed | Max. 1/2 Cycle + 1 ms |
| Insulation resistance | 500 V d.c. 100 MΩ (input/output and among cases) |
| Dielectric strength | 2,500 V a.c. (60 ㎐ for one minute) |
| Vibration resistance | 10 -55 Hz, double amplitude: 1.5 mm, each X· Y· Z axis for 2 hours |
| Shock resistance | 1,000 m/s² each X· Y· Z axis for 3 times |
| Storage temperature | -30 ~ 90 ℃ |
| Ambient temperature | -20 ~ 80 ℃ (without condensation) |
| Ambient humidity | 45 ~ 85 % R.H. |
| Load Category | LC A |
| IP Degree | IP20 |
| Pollution degree | 2 Rating |
| Weight | Approx. 670 | Approx. 900 | Approx. 670 | Approx. 900 |
