Explore performance details, construction highlights, applications, and technical information in one clear overview.
The SVA Solenoid Valve is a vacuum-operatable 2/3-port valve designed for precise control of air flow in industrial automation systems. It enables reliable on/off switching of fluid lines without requiring external pilot piping, making it ideal for applications where space and complexity are limited. The valve operates efficiently under both positive and negative pressure conditions, offering flexibility in system design while maintaining high performance.
Constructed with durable materials suitable for continuous operation, the SVA features a robust internal structure that ensures long-term reliability. Its lightweight and compact design delivers large capacity through an effective sectional area of 18mm² within a 16mm width valve body. The valve is built to withstand operational stresses and environmental conditions typical in industrial environments.
The SVA offers two options for connector lead-out direction: top or side, allowing users to select the configuration that best fits their mounting layout and wiring requirements. For manifold-type models, a check valve to prevent back pressure is available as an optional feature, and dual pressure control can be selected to manage two different pressures within a single manifold unit.
The SVA operates within a pressure range of 0.2
| Specification | Details |
|---|---|
| Fluid medium | Air |
| Operating pressure range | 0.2
