Explore performance details, construction highlights, applications, and technical information in one clear overview.
The SG-BWS-T4-MT - 957051010 - Safety Light Curtain is a industrial product from Datasensing. The documented values above identify the exact configuration and are the basis for technical selection and system integration.
The Datasensing SG-BWS-T:4-MT - 957051010 Safety Light Curtain is engineered for industrial safety applications. It provides a 2 relay NO output with a 35ms response time, operating within 24Vdc ±15% voltage range. The device supports cable lengths up to 50m for both power supply and output connections.
Constructed from durable PA66 plastic, this light curtain operates reliably across a temperature range of 0°C to +55°C. Its storage temperature tolerance spans -25°C to +70°C, ensuring stability in diverse industrial environments. The IP20 mechanical protection rating provides basic dust and liquid resistance.
The documented configuration includes Response time: 35 ms; Nominal sensing distance: According to the sensors used: S5*ST* up to 8m; SL5*ST and S300*ST4 up to 40m; S300*ST2 up to 50m; Emission: n/a; Emission: Power Consumption - Receiver.
The documented configuration includes Output type: 2 Relay NO; Operating Voltage: 24 Vdc ± 15%; Cabel Length (Power Supply/Output): ≤ 50m; Power consumption: ≤ 3,8W; Cable Length (sensors): ≤ 50m; Power Consumption - Receiver: n/a; Power Consumption - Emitter: n/a; Power Consumption - Emitter: Cabel Length (Power Supply/Output).
The documented configuration includes Dimensions: 68x99x119; Material: Plastic - PA66; Storage temperature: -25…+ 70°C; Dimensions: 68x99x119 mm; Operating Temperature: 0…+55°C; Mechanical Protection: IP20; Storage temperature: 25…+ 70°C; controlled height: n/a.
The documented configuration includes controlled height: Application.
The documented configuration includes Safety control unit pl: e double muting 2 pairs of sensors; Available functions: Manual/Automatic Restart, EDM, Double Muting, Override; Max. number of muting sensors: 4 x PNP-NO; Functions: 4 safety light beam inputs - muting; Function Principle: 4 x S5*ST/SL5*ST/S300*ST pairs; Long operating distance: up to 50 m; Function Principle: Control unit.
The documented configuration includes Type: Type 4 safety control unit (A/M); Vibrations: Width 0.35 mm, frequency 10 … 55Hz; 20 sweep per axis, 1octave/min (EN 60068-2-6); Shocks: 16 ms (10 G) 1,000 shocks per axis (EN 60068-2-29); According to the sensors used: S5*ST* up to 8m; SL5*ST and S300*ST4 up to 40m; S300*ST2 up to 50m; Connections: Terminal block; Connections: Storage temperature; Effective Aperture Angle: n/a; Interference to external light: n/a.
| Feature | Specification |
|---|---|
| Output type | 2 Relay NO |
| Response time | 35 ms |
| Operating Voltage | 24 Vdc ± 15% |
| Cabel Length (Power Supply/Output) | ≤ 50m |
| Dimensions | 68x99x119 |
| Material | Plastic - PA66 |
| Storage temperature | -25…+ 70°C |
| Dimensions | 68x99x119 mm |
| Operating Temperature | 0…+55°C |
| Mechanical Protection | IP20 |
| Storage temperature | 25…+ 70°C |
| Safety control unit pl | e double muting 2 pairs of sensors |
| Nominal sensing distance | According to the sensors used: S5*ST* up to 8m; SL5*ST and S300*ST4 up to 40m; S300*ST2 up to 50m |
| Available functions | Manual/Automatic Restart, EDM, Double Muting, Override |
| Max. number of muting sensors | 4 x PNP-NO |
| Functions | 4 safety light beam inputs - muting |
| Type | Type 4 safety control unit (A/M) |
| Power consumption | ≤ 3,8W |
| Cable Length (sensors) | ≤ 50m |
| Vibrations | Width 0.35 mm, frequency 10 … 55Hz; 20 sweep per axis, 1octave/min (EN 60068-2-6) |
| Shocks | 16 ms (10 G) 1,000 shocks per axis (EN 60068-2-29) |
| Function Principle | 4 x S5*ST/SL5*ST/S300*ST pairs |
| Long operating distance | up to 50 m |
| According to the sensors used | S5*ST* up to 8m; SL5*ST and S300*ST4 up to 40m; S300*ST2 up to 50m |
| Connections | Terminal block |
| Connections | Storage temperature |
| controlled height | n/a |
| Effective Aperture Angle | n/a |
| Function Principle | Control unit |
| Emission | n/a |
| Interference to external light | n/a |
| Power Consumption - Receiver | n/a |
| Power Consumption - Emitter | n/a |
| controlled height | Application |
| Emission | Power Consumption - Receiver |
| Power Consumption - Emitter | Cabel Length (Power Supply/Output) |
