Series MIXPG Isometric pressure gauge - Isometric pressure gauge 63 mm

The Series MIXPG Isometric pressure gauge - Isometric pressure gauge 63 mm is part of the Control Process range of pressure and temperature instruments and is configured for direct local measurement. This version is identified as MIXPG 63 mm. The product format, case construction and connection arrangement are based on the corresponding Control Process series, making the instrument suitable for integration into industrial measurement points where clear local indication is required.

For this configuration, the principal construction is stainless steel + brass family construction and the mounting/connection arrangement is rear/center-back configuration. The specified internal construction is brass/copper-alloy process construction. The indicating assembly is described as isometric scale with coloured sectors for visual indication, while the stated design reference is Control Process isometric series. Where a numerical accuracy value is specified for the selected configuration, it is configuration-dependent; otherwise the accuracy remains configuration-dependent rather than being assigned from case diameter alone.

The Control Process range includes the MIXPG family with 63 and 100 mm case sizes and configuration-dependent. The listed connection options for the relevant mechanical families include standard instrument/process thread sizes such as 1/8, 1/4 and 1/2 inch, with additional configurations available where stated in the series ordering information. The pressure range shown for a family is a series capability; the actual scale fitted to an individual instrument depends on the selected configuration and ordering code.

For installation and operation, the selected mounting arrangement should be matched to the process connection and panel or instrument position. The specified temperature information for this configuration is configuration-dependent. This makes the instrument suitable for use where the specified mechanical construction, indication format, connection arrangement and operating conditions match the application requirements. The product should be selected using the complete Control Process configuration code when a specific pressure scale, connection or temperature range is required.
